Home > Products > AMPOULE EQUIPMENTS > Automatic Ampoule Fiiling and Sealing Machine
Automatic Ampoule Fiiling and Sealing Machine
- 30 Set / Sets per Month
- Shanghai Nantong
- T/T L/C D/P D/A Credit Card PayPal
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Beverage, Chemical, Commodity, Medical | Packaging Type: | Bottles |
Packaging Material: | Glass | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220V | Place of Origin: | Jiangsu, China | Brand Name: | BETTER |
Model Number: | BM-6 | Certification: | ISO, CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Automatic Ampoule Fiiling and Sealing Machine
Automatic Ampoule Fiiling and Sealing Machine
Introduction:
Filling and sealing machine for ampoule Model BM-6 is equipment specifilized in filling and sealing 5ml to 10ml,10-20ml bottle in pharmaceutical works.This machine is equipped with automatic stop-filling device which can make filling case when there is no ampoule into filling station.
Suitable for pharmaceutical ampoule filling and sealing drawing, the local station for the 6 bottles for one stepper drive system, each with 6 bottles as a group, were sent to the various processes point to complete the delivery bottles, before nitrogen, drench, after nitrogen, preheated, drawing sealing processes.
Using hydrogen generator, the interface is fully matched. Drive rack stainless steel, pressure bottle tied tight fit.
Technical parameter
Voltage | 380V,50/60HZ(cutomized by different country) |
Power | 0.8KW |
Filling Nozzles | 6 Nozzles |
Applicable volume | 5ml-10ml(cc),15-20ml |
Yield capcacity | 8000-12000pcs/hour |
Dimension | 1650*900*1500mm |
Weight | 350kg |
Ampoule Filling & Sealing Machine Packing List
- Glass 8 holes 2 pcs
- piston 18 pcs
- drencher 4 pcs
- chain link of sending bottles 10 pcs
- discharging baffle 7 pcs
- needles 6 pcs
- 5-20ml Ampoule filling & sealing machine 1 set
1.How about your Automatic Ampoule Fiiling and Sealing Machine quality?
Better is a mature brand in CHINA,through our many years research in technology. our design including structure and detailed security and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are Better machines.
2. What’s your after-sale service?
Better provide oriented after-sales service including the oversea engineers training available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where are you.
We welcome engineers from your side to learn the technical design and normal maintenance here,this will help your easy in understanding and helpful if you need to be our dealer.
3. How to operate your Automatic Ampoule Fiiling and Sealing Machine?
Don’t worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing documents to deepen your knowledge and understanding. Anyhow there are another way is through internet video face to face for machine teaching, because of the high development in internet,the world has become smaller and you can easy catch us if any assistance needed .
