l With 32 bit high-speed ARM CPU, integrated USB2.0 transmission protocol, greatly enhance the transmission speed, reading ability and reading speed. The maximum reading of up to 1.5 m reading depth. Decode100 bit long and more than 28CM barcodes.
l Added latest GSI barcode decoding, while enhancing the dynamic fuzzy recognition technology, wore out, dirty, silver color background, anti-white bar code can be easily read.
l Adopts ergonomic design, with a compact, light -weighted, comfortable features.
l Adopts high quality laser configuration, stable performance, lifespan more than 20,000 hours.
Technical Parameters |
|
|
ZD2250 + wired barcode scanner |
ZD2250+AT |
|
Operating mode |
Manually/ Continuously Scan |
Manually/Continuously/Auto-induction Scan |
Decoding CPU |
32-bit ARM Micro Processor |
|
Input voltage |
DC 5 V±0.25 V |
|
Power |
175mW(Standby);525 mW(Max.) |
|
Current |
35 mA(Standby);105 mA(Max.) |
|
Light Source |
Visual laser diode,Wavelength:630-650 nm |
|
Decoding Rate |
Data output rate: 33±2 times/sec Decoding:200 times/sec |
|
Scanning Angle |
±60°,±65°,±42°(Skew/Pitch/Roll) |
|
Decoding Capacity |
Decode all 1-D barcode including GSI DataBar: UPC-A,UPC-E,EAN-13,EAN-8,ISBN/ISSN,Code39,Code39(regular),Interleaved 2 of 5,CODABAR,CODE 128,HIBC,Code 93,UCC/EAN 128,GS1 DataBar,GS1 Databar Omnidirectional,GSI DATABAR Expanded, GS1-128, GS1 Databar Expanded Stacked(formerly RSS) |
|
Indicator |
Beeper,LED |
|
Cable Interface |
RS-232(Optional);USB 2.0(Standard );Cable Length:1.8m.(Bracket Optional) |
|
Dimension |
Width ×Depth× Height:95 mm×67 mm×154 mm |
|
Weight |
125 g |
|
Temperature |
0°C --50°C(Operating);-40°C --60°C(Storage) |
|
Humidity |
5%--95%(non-condensing) |
|
DecodingRange (1mil=0.0254mm) |
5 mil: 55-200mm |
10 mil: 55-410mm |
13 mil: 60-510mm |
16 mil: 65-820mm |
|
|
35 mil: 65-1050mm Depth of field up to 1.5 meter, Scan 100 bit and 28cm barcode | ||
Safety |
Laser Safety:EN60825-1,class 1 |
|
Electrical Safety : EN 60950-1 | ||
CE-EMC: EN 55022,EN55024 | ||
Durability: Multiple 1.5m drop to concrete floor | ||
Case Material:Fire-resistant material,Medical antibacterial material(For the pharmaceutical industry or project) | ||
Certification |
IEC(Laser Safety),CE,IP54,FCC,ROHS,3C |
|
