ZD6168 Bluetooth 2D image barcode scanner | ||||
Appearance |
|
Features: |
||
|
|
With self-intellectual property; |
||
|
Press-key comes with up to 3 million times pressing life; |
|||
|
Adopt CMOS image technology and advanced intelligent image recognition system, can read almost all 1D&2D barcodes in the market. |
|||
|
Adopt red LED auxiliary lighting system, can read barcode easily even in dark environment. |
|||
|
Adopt advance Bluetooth 3.0 transfer profile. |
|||
|
More working modes are optional for you, normal mode for data real time transmission or checking mode for data bulk uploading. Built-in large capacity lithium battery; |
|||
Performance parameter |
|
Physical parameter |
||
Light type: |
Red LED, Wave length:625nm |
|
Size |
160mm×70mm×90mm |
Scanning mode: |
2D image barcode recognition engine |
|
Weight |
271.3g |
Tech type |
CMOS image technology |
|
Material |
ABS+PC |
Resolution |
640*480 /752*480 |
|
Cable: |
1.8m |
Scanning accuracy |
>=5mil |
|
Shock resistance |
Pass 1.5M dropping test |
Scanning depth |
EAN-13 50-260mm (13mil) |
|
Environmental parameter |
|
Scanning angle |
Rotation 360°,Gradient:+/-55°, Deviation:+/-55° |
|
Working temperature |
-10℃__50℃ |
Symbol contrast |
>=25% reflection difference |
|
Storage temperature |
-20℃__60℃ |
Visual angle: |
Horizontal: 26°,Vertial:23° |
|
Humidity |
Relative humidity 5%-95%(No condensation) |
Decoding ability |
2D:PDF417,QR Code,Data,Matrix,(ECC200,ECC000,050,080,100,140) 1D:Code128,EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codabar,Interleaved 2 of 5,ISBN/ISSN,Code 93,UCC/EAN-128,GS1 Databar etc |
|
Brightness: |
Max.4,500 Lux(CFL) |
|
Electronic parameter |
|||
Interface |
Bluetooth 3.0 HID mode |
|
Voltage: |
5V |
|
Current: |
270mA(working);94mA(Standby) |
||
Prompting mode |
Buzzer, indicator light |
|
EMC |
FCC Class A, CISPR Class A |
Scanning method |
Manual |
|
Electrostatic protection |
15KV |
Send Inquiry to This Supplier
