50 Inch Floor Stand Touch Screen Digital Signage

50 Inch Floor Stand Touch Screen Digital Signage photo-1
US$ 577 - 1,777 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DDW
Model Number:
DDW-LW5001
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name DDW
Model Number DDW-LW5001
Type TFT
Application Indoor
Panel Size 50"
Max Resolution 1920*1080
Viewing Angle 178x178
Pixel Pitch 0.63x0.63mm
Color 8bits,16M
Contrast Ratio 4000:1
Brightness 450nits
Response Time 5ms
Input Voltage 110-220V

50 inch  5.3mm floor stand touch screen digital signage





 features:
1,Original 50inch SHARP Industrial grade LCD video wall panel,16:9 LG a-Si TFT-LCD
2,LED backlight,450 brightness

3,HD physical resolution 1920*1080
4,Only 5.3mm Ultra narrow bezel.high quality ,Practical ,good vision effect.
5,Signal interface rich --- RS232, HDMI,DVI,VGA,Y Pb Pr ,AV
6,HD video wall unit--- High brightness,high contrast,High gamut .
7,Flexible structure design ---easy installation ,extensible,arbitrary combination
8,Stable performance,suitable working for a long time





Specifications



Model No.DDW-LW5001
Panel Specifications
LCD TechnologySharp a-Si TFT-LCD
Active Screen Diagonal50"
Pixel Pitch(WxH)0.630x0.630mm
Active Display Area(WxH)1328.8x747mm
Panel Dimension(WxHxD)1335.9x754.2mm
Total Bezel Width5.3mm
Aspect Ratio16:9
Physical Resolution1920*1080
Backight SystemWLED
Luminance(nits)450cd/sqm
Contrast4000:1 (typ.)
Viewing AngleH 178°|V 178°
Display Colors8Bit,16.7M
Refresh Rate60Hz
Response Time<=5ms
Life(hrs)>60,000(hrs)
MTBF> 100,000 h
SurfaceAnti-glare
Standby Power Consumption<3W
Maximum Power Consumption<=270W
Power SupplyAC100~240V 50/60 HZ
CoolingLow noise fans
Heat Dissipation819 BTU/h (max)
Working Time Capacity7x24x365hours
Application AreaIndoor/Semi Outdoor/Outdoor
Working Temperature0°C~50°C
Working Humidity85% non-condensing
Storage Temperature-20-60°C | -4-149°F
Storage Humidity85% non-condensing
Daisy chain video wall controller
DVI-I DUAL LINK1
HDMI1
VGA1
CVBS IN1
CVBS OUT1
RS232 IN1
RS232 OUT1
ISP IN1
IR IN1
CODING BUTTON1
AC INAC100-240V
Color System SupportPAL/NTSC/SECAM
Control TypeIR Remote &Software Control
Menu LanguageEnglish/Chinese(Multiple Language can be customized)



50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage50 inch floor stand touch screen digital signage

 FAQ

1. Q: Are you a manufacturer or trading company?
A:We are a manufacturer who has been specializing in producing LCD display for years.

2. Q: How does your factory do regarding quality control?
A:Quality is priority.DDW people always attach great importance to quality controlling from the

very beginning to the very end. We focus on every detail ,Our factory has gained ISO9001, ISO14001, CE, RoHS authentication.

3. Q: What is your after-sale service?
A: We offer 100% guarantee on our product .

4. Q: What is your MOQ?
A: Any quantity is acceptable for your order. And the price is negotiable for large quantity.
5. Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days according to the size and quantities
of your order.
6.Q:what brand of screen are you using?
A:we are using Samsung,LG,AUO and CHIMEI screen.
7.Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
8.Q:if you are not online,how can i get contact with you?
A:if i am not online,please kindly check the following contact information,you can send me email,you can call me or skype me,i will reply you ASAP.





Any problem,please feel free to contact with us.
