Flexible transparent lcd display box
Samsung original DID screen
LED backlight,500nits brightness
FHD 1920*1080 resolution
HDMI DVI VGA AV BNC multiple signal sources
Model No.: DDW-LW4601
transparent lcd display features:
1,Original 46inch Samsung Industrial gradelcd video wall screen,16:9 LG a-Si TFT-LCD
2,LED backlight,500nits high brightness
3,HD physical resolution 1920*1080
4,Only 5.3mm Ultra narrow bezel.high quality ,Practical ,good vision effect.
5,Signal interface rich --- RS232, HDMI,DVI,VGA,Y Pb Pr ,AV
6,HD video wall unit--- High brightness,high contrast,High gamut .
7,Flexible structure design ---easy installation ,extensible,arbitrary combination
8,Stable performance,suitable working for a long time
backpack lcd advertising display is one of Samsung most popular ultra narrow bezel lcd video wall panels. With 5.3mm ultra narrow bezel, LED backlight and FHD 1080P resolution, it can be widly used in below fields: Conference and meeting rooms, office building, lobbies, Security Monitoring Center, Surveillance and Retail Center, Restaurant and hotel, Retail Shopping Mall Advertising and information Displays, Public Installations, Exhibition and show center, Live show,Rental and advertising Center,Museums,Church,Transportation and Mass Info Display systems.
Specifications
| Samsung 46 inch seamless tv wall Specifications | |
| LCD Technology | SAMSUNG DID LCD |
| Active Screen Diagonal | 46" 16:9 |
| Bezel Width | Total: 5.3mm |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920*1080 |
| Backight System | LED |
| Luminance(nits) | 500cd/sqm |
| Contrast | 3500:1 |
| Viewing Angle | H 178°|V 178° |
| Pixel Pitch(WxH) | 0.53025x0.53025mm |
| Active Display Area(WxH) | 1039.8675×584.64mm |
| Panel Dimension(WxHxD) | 1023.98x578.57x49.5mm |
| White Point | 10,000 K |
| Display Colors | 8Bit,16.7M |
| Refresh Rate | 60Hz |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| MTBF | > 100,000 h |
| Surface | Anti-glare |
| Standby Power Consumption | <3W |
| Maximum Power Consumption | lower than 220W |
| Power Supply | AC100~240V 50/60Hz |
| Cooling | Low noise fans |
| Heat Dissipation | 819 BTU/h (max) |
| Working Time Capacity | 7x24x365hours |
| Application Area | Indoor/Semi Outdoor |
| Working Temperature | 0°C~50°C |
| Working Humidity | 0.85 |
| Storage Temperature | -20-60°C | -4-140°F |
| Storage Humidity | 85% non-condensing |
| Daisy chain videowall controller specifications | |
| DVI-I DUAL LINK | 1 |
| HDMI | 1 |
| VGA | 1 |
| CVBS IN | 1 |
| CVBS OUT | 1 |
| RS232 IN | 1 |
| RS232 OUT | 2 |
| ISP IN | 1 |
| IR IN | 1 |
| CODING BUTTON | 1 |
| AC IN | AC100-240V |
| Color System Support | PAL/NTSC/SECAM |
| Control Type | IR Remote &Software Control |
| Menu Language | English/Chinese(Multiple Language can be customized) |
| Vertical/Horizontal Display | Support |
| Combine Display | Support combine any horizental &vertical numbers of screens and show display |
| Support combine all screens together to show 1image | |
| Solid Display | Support each screen input with separate signal |
| PIP/Zoom/Roaming | Support open one window for each screen, each window can be zoomed &roaming internal freely |
| Multiple Interfaces | Support DVI,HDMI,VGA,AV &multiple signal inputs |
| Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolution inputs |
| Dimension(WxHxD) | 318.4x332x56mm |
FAQ
1. Q: Are you a manufacturer or trading company?
A:We are a manufacturer who has been specializing in producing LCD display for years.
2. Q: How does your factory do regarding quality control?
A:Quality is priority.DDW people always attach great importance to quality controlling from the
very beginning to the very end. We focus on every detail ,Our factory has gained ISO9001, ISO14001, CE, RoHS authentication.
3. Q: What is your after-sale service?
A: We offer 100% guarantee on our product .
4. Q: What is your MOQ?
A: Any quantity is acceptable for your order. And the price is negotiable for large quantity.
5. Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days according to the size and quantities
of your order.
6.Q:what brand of screen are you using?
A:we are using Samsung,LG,AUO and CHIMEI screen.
7.Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
8.Q:if you are not online,how can i get contact with you?
A:if i am not online,please kindly check the following contact information,you can send me email,you can call me or skype me,i will reply you ASAP.
Contact with us for details of lcd video wall now and get free assessments for your project and get preferential prices!
