Water-cooled Silent Type Quanchai 24KW Diesel Generator

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	hiearns:Water-cooled silent diesel generator(GF2-30KVA)
Model Number	GF2-30KVA	Output Type	AC Three Phase
Speed	1500rpm/1800rpm	Frequency	50/60HZ
Rated Power	24KW	Rated Voltage	220/380, 230/400V
Rated Current	43.3

water-cooled silent type Quanchai 24KW diesel generator

Standby Power	25 KW / 31.25KVA
Prime Power	24KW / 30KVA
Model	4102D
Cylinder Number	4
Bore×Stroke(mm)	102×118
Displacement(L)	3.857
Rated RPM(r/min)	1500
Rated Speed Regulation %	≤5
Rated Fuel Consumption(g/kW·h)	≤238
Cylinder Head Type	Dry type
Diesel Generator Type	Direct line,Water-cooled,Four stroke
Intake Type	Natually-Aspirated
Combustion Chamber Type	Direct Injection
Lubricating System	Pressure,Split,Complex
Flywheel Cover Specification	SAE4#
Flywheel Specification	SAE7.5″
Exhaust Fan Diameter(mm)	φ410
Flywheel Teeth Number	109
Add Oil Capacity	6.5L
Voltage (V)	380/220
Frequency (HZ)	50
Insulation Class	H
Rated Current (A)	43.3
Phase	3
Altitude	≤1000m
Power Factor	0.8
Voltage Regulation,Stead State	≤±1%
Connecting Type	3 Phase and 4 Wires,"Y" type connecting
AVR	SX460
Environment Temperature (°c)	40
Exciter Type	Brushless,self-exciting
Protection Grade	IP23
Silent Type's Dimension Length × Width × Height (mm)	2120×965×1200
Silent Type's Net Weight(Kg)	802
Silent Type's 20FT Loading Quantity	6PCS

Packaging & Shipping

♦ From the engine to generator, we all use 7 layer corrugated carton packing, plywood pallet, Ensure a portable and safety transport!
