1.Product intruduction of ultrasonic hydraulic oil Flow Meter
GXUF-2000 series flow meter usually is used to long-term measure at field. It's easy to use and easy to repairing without cut off the piple,without turn off the fluid.Both the sensor and the host can be installed
on the pipes. The protect grade is Ip68, can be used as calorimeter, if the temperature sensor added
2.Feature of ultrasonic hydraulic oil Flow Meter
High flow acurracy
Up to1%
Wide range of flow rate and pipe diameter
Suitable for the pipe with Dn15 toDN6000
High reliability
working life up to 10 years
Robust design
Differential signal driver and reciever, immune to low frequency transformer and Tv signal and power transmission.
huge storage function
Support 512 days and 128 months and 10 years accumulated flow result,Auto save 64 times power on and off time and flow rate.
Auto save 32 days work status of the meter
Remote transmission and net work transmission
Rs485 interface support Mod-bus protocol and easy to support GPRS or Zigbee networking
Easy to used for calorimeter
Can be used as Calorimeter after the temperature sensor installtion
3.Brief
Smart ultrasonic flow meter can be used to measure various kind of fluid in the application field of tap water, heating, water
conservancy, metallurgy, chemical industry, machinery, energy indurstry.
both sensors and the host can be installed at the pipe. also can be used as calorimeter
4.Measure
5.Application field
Water supply Heat supply Intelligent building Metallurgy Peroleum Powersupply
6. Sensor selection table
sensors selection depend on the application field parameters such as the diameter of the pipe the fix method the kind of the flow back view of terminal pole front view with cover off back view with cover off 5 Powermodule(optional):AC85-265V Front view. Please refer to the fix method choice chapter for details
7. Optional temp sensor
| Picture | Description | Type No. | Piperange | Temp | Fix con | Accuracy |
|
3-wire PT100 clamp on type |
CPT 3 | >DN50 | 40~160°C | easy | 100°C±0.8°C<0.1°C |
|
3-wire PT100 Plug in type |
PPT 3 | >DN50 | 40~160°C | shut flow down | |
|
3-wire PT100 without pressure loss plug in type |
LPT 3 | >DN50 | 40~160°C | easy | |
|
mini 3-wire PT100 plug in type |
MPT 3 | >DN50 | 40~160°C | shut flow down |
8. Description of parts
|
|
|
|
9.Parameters
10. ordering info
Please contact us for more details
Packaing Detail: Standard export carton or wooden box.
11.Our company show
Our other products for your referance
Pressure transmitter :
Differential pressure transducer :
Gauge :
Controller :
Flow meter :
Pressure Transducer :
Ultrasoinc Transducer :
Inertial Navigation Sensors :
Level Sensor ;
Vibration Isolator ;
We supply high quality flow meter, please let us know your requirements, we will try best to provide most suitable solution for you. Please feel free to send us an inquiry, we will reply you within 24 hours.
