TAIYITO China R&D Manufacturer Industry Leader Domotica Zigbee wireless smart home control solutions

Zigbee Protocol

IEEE 802.15.4

Appliances

1. lighting/lamp system(ON/OFF and dimming)

2. household electric apparatus(TV,AC,DVD,water heater,fans,ETC

3. window, electric curtain(Open/Close/Stop)

4. door lock(Open/Close)

5. AV, background music(ON/OFF/Channel/Volumn...)

6. home alarm system and other security products

7. home monitor system

Function control

1.IOS/ Android smart phone Apps control

ephone long distance control

3.Scene control;

4.wall centralized control;

5.remote control;

6.Timing control

Controlled products

(receive commands)

Controller products

(send sommands)

TDX4467     Flat-open Electric & Manual Curtain Motor

TDX4467G  Flat-open Electric & Manual Curtain Rail

TDX4466     Flat-open Electric & Manual Curtain Motor

TDX4466G  Flat-open Electric & Manual Curtain Rail

TDX4469     Roller Blind Electric Curtain Motor(10N)

TDX4468G  Roller Blind Elctric Curtain Track( φ50 )

TDX6618H  Network Camera( 3 M Pixels)

...

4Steps: (in the standard 86 type junction box)

   Step1: do wire connection

   Step2: do networking

   Step3: setting gateway and apps

   Step4: setting address code

Controller Products(applies to Zigbee system; high-speed bidirectional communication. )

TDWZ6617

Zigbee Network Service Controller(Including IOS/Android Software)

 1.relevant softwares are attached.

 t2.o control through the computer indoor or far away

TDWZ6618

Cloud Box of Smart Home Network Control Host(With WiFi and IEEE international standard ZigBEE communication module built inside)

1. Cloud server, Webchat remote control.

2. multiple functions and multiple interfaces.

TDWZ6436

Zigbee IR Transceiver

can be controlled through both local and long-distance telepnone and mobilephone anywhere.

TDWZ6000S

Coordinate

used to do networking in zigbee system, you must have it in this system.

Controlled Products

(applies to Zigbee system;High-speed bidirectional communication)

TDZ4203M

Zigbee Touch Screen Fluorescent

Lamp/Appliance Switch (Max1500W)

Max 1500W,control light

TDZ4204M

Zigbee Touch Screencrystal lamp Switch(Max1500W)

Max 1500W, control Screencrystal lamp.

TDZ4404M

Zigbee Touch Screen 2-way Fluorescent Lamp/Appliance Switch

Max 300W for each way, control the light

TDZ4405M

Zigbee Touch Screen 3-way Fluorescent Lamp/Appliance Switch

Max 300W for each way, control the light

TDZ4406M

Zigbee Touch Screen 4-way Fluorescent Lamp/Appliance Switch

Max 300W for each way, control the light(LED less 10W).

TDZ4401M

Zigbee Touch Screen Dimmer Switch

Max 500W, control and dimmer the light

TDZ4466M

Zigbee one way Touch Screen Automatic Curtain Switch

control one way electric curtain

TDZ4468M

Zigbee two way Touch Screen Automatic Curtain Switch

control two way electric curtain

TDZ4470M

Zigbee one way Touch Screen Automatic Curtain Switch for TDX4470

control one way electric curtain, work with TDX4470

TDZ4473M

Zigbee one way Touch Screen Automatic Curtain Switch (the curtain motor has independent stop key)

control one way electric curtain, work with the motor has independent stop key

TDZ4464M

Zigbee Touch Screen Window Opener Switch

control Window Opener

TDZ4488M

Zigbee Touch Screen Fingerprint door lock Switch

control Fingerprint door lock

TDZ4462M

Zigbee Touch Screen mechanical arm Switch

Work together with TDX6840

TDZ4486M

Zigbee Touch Screen Electric clothes airer Switch

control Electric clothes airer

TDWZ6402M

Zigbee Touch Screen 2-way Scene Switch(Max 16 addresses per scene)

control IR appliance

TDWZ6403M

Zigbee Touch Screen 1-way double control stair hall switch

control lamp,appliance

TDWZ6404M

Zigbee Touch Screen 2-way double control stair hall switch
