Specifications
H13 HEPA panel for clean roomMedia:glassfiber
Frame:Aluminum profile
Efficiency:99.97% at 0.3um
H13 HEPA panel for clean room
ISO 9001 Cerification
1.air filterof low initial resitance
2.large dust holding capacity
3.filter economical,long serice life
4.cheap
Description:
Mini-pleat HEPA filters are mainly used to filtrate the suspended particles in the air with the diameter of 0.3um and below and used for the terminal filtration of all kinds of filtration systems.
Application:
H14 Mini-pleat HEPA filter are extensively used in the terminal filtration of the civil or industrial cleansing places in the industries such as electron, semiconductor, precision mechanism, pharmacy, hospital and food, etc., which required relatively high cleanliness factors.
Material and operating conditions:
External frame |
Aluminum |
Sealant |
Polyurethane |
Separator |
Hot-melt |
Filter media |
Glass fiber |
Maximum operating temperature |
80°C |
Maximum operating humidity |
80% |
Standard size and specification:
Model |
Outside dimensions(mm) |
Rated air flow (m³/h) |
Initial resistance (Pa) |
Efficiency(%) |
ZS-GW3051 |
305x305x50 |
180 |
≤220 |
≥99.99 |
ZS-GW3052 |
305x305x69 |
250 |
||
ZS-GW6101 |
610x610x50 |
700 |
||
ZS-GW6102 |
610x610x69 |
100 |
||
ZS-GW9151 |
915x610x50 |
1100 |
||
ZS-GW9152 |
915x610x69 |
1500 |
||
ZS-GW1200 |
1220x610x69 |
2000 |
||
ZS-GW3052 |
305x305x80 |
300 |
||
ZS-GW6102 |
610x610x80 |
1300 |
||
ZS-GW9153 |
915x610x80 |
1900 |
||
ZS-GW9154 |
915x610x90 |
1900 |
