4-20ma Liquid Water Level Sensor / Fuel Tank Level Sensor

Name: 4-20ma Liquid Water Level Sensor / Fuel Tank Level Sensor
Brand: GX support OEM
SKU: 104226503
Availability: InStock

US$ 99 - 390 MOQ: 1 Piece

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

GX support OEM

Model Number:

GXPS400

Xi'an Kacise Optronics Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or other

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name GX support OEM

Model Number GXPS400

Usage Level Sensor

Theory Resistance Sensor

Output Analog Sensor

GXPS400 serial 4-20ma liquid water level sensor

1. Specification of GXPS400 serial 4-20ma liquid water level sensor :

Spec.	Numerical value			Remark
Pressure range	0~1……500mH2O			1mH2O≈9.81kPa
Overload pressure	1.5times Rated pressure
fracture pressure	3 times rated pressure
Accuracy	±0.25%F.S, ±0.5%F.S, ±1.0%F.S
Accuracy	±0.25%F.S, ±0.5%F.S, ±1.0%F.S
Stability	Typical value: 0.1%F.S Max.: 0.2% F.S/year
Operating Temperature	-40°C~85°C or -40 °C ~125 °C
compensation temperature	-10°C~70°C
medium compatibility	All Caustic Medium Compatible with 1Cr18Ni9Ti and 316L
electrical properties	2 line	3 line
Output signal	4~20mA	0~5V	0~10V
Power supplies	10~30Vdc	80~30Vdc/ac	11~30Vdc/ac	Vdc/ac
load resistance	(U-10)/0.02( Omega )	more than 100k Omega
insulation	more than 100M Omega @50V
Electrical Connections	waterproof fixed cable + Two rectangle circle+Sealing Rings+seal gum+ Pure glue protection grade : IP68
pressure interface	G1/4,input type
response time	10ms
Electric strength	500Vac@1 second
Graduate Certificate Programs	certificate of explosion-proof, CE
electromagnetic compatibility	electromagnetic radiation EN50081-1/-2, electromagnetic susceptibilty: EN50082-2
lightning protection	air conduction resistance 8000V,case, cable conduction
