Specifications
ffu fan filter unit1) Low vibration and noise
2) Air velocity:0.35-0.6m/s
3) Efficiency: H13
4) Aluminum coated zinc plate
FFU ( Fan filter unit, Hepa filter& fan)
ffu fan filter unit
ISO9001 Certification
Feature:
1 The material of FFU is stainless steel, galvanized aluminum sheet or cold rolled steel, which is beautiful and prevent to rust
2 Efficiency:H13 filtering 0.3um
3 Air velocity: 0.35-0.6m/s
4 Noise:Less than 53dBA
5. Voltage:AC220V/50Hz/1Ph
Usage:
FFU can be connected for modularized application enables it to be widely applied to clean room, clean bench, clean production line, assembled clean room or local class 100 clean booth.
Optional accessory:
- Material: Cold rolled steel plated with powder, stainless steel or Galvanized Aluminum sheet
- Round duct interface or Square Duct interface
- HEPA filter or ULPA filter
- Pre filter
- Common fan or EBM fan
- Remote control
Standard size and specification:
Item Model |
ZS-FFU610 |
ZS-FFU915 |
ZS-FFU1170 |
ZS-FFU1220 |
|
Size for cabinet(mm) |
610x610x240 |
915x610x240 |
1170x570x240 |
1220x610x240 |
|
Material |
Cold Rolled steel with powder coated/aluminum coated zinc plate/SUS#201 or 304 |
||||
Air flow(m3/h) |
600 |
900 |
1080 |
1200 |
|
Air velocity(Tested under filter 300mm) |
0.35-0.6 m/s |
||||
ESP |
80-120pa |
||||
Hepa filter |
Size(mm) |
610x610x69 |
915x610x69 |
1170x570x69 |
1220x610x69 |
Frame |
Aluminum profile |
||||
Media |
Fiberglass |
||||
Efficiency |
H13 @0.3um |
||||
Pressure Drop |
≤220pa |
||||
Fan(motor) |
Power |
AC 220V/50Hz;AC110V/60Hz |
|||
Noise(dB) |
52 |
52 |
52 |
53 |
|
Optional |
Control panel, Remote control, Pre filter, Pressure gauge |
||||
Weight(KG) |
22 |
24 |
28 |
32 |
|
