Specifications
Aluminum Square ceiling air diffuser1.Anodized/powder coated
2.Aluminum alloy
3.OBD/neck adaptor
4.All size is available
Aluminum Square ceiling air diffuser
Square air diffuser
Square ceiling air conditioning diffuser
Construction:
Frame:High quality extruded aluminum alloy profile with 27.5mm width border
Core:High quality extruded aluminum ally profile
Material thickness:0.8mm,1.0mm for option
Color: white can also follow customer’s requirement
Surface finish: powder coated/Anodized.
Size:Face size= neck size+145mm
Border width:32mm
Height:50mm
Features:
1. Excllent appearance , fit for supply airflow
2. The multiplayer cone divided the air into many layers of swift puffs, quickly mixing the inlet air and interior together
3.Louvered type core is fixed to frame with aluminum pins loaded with steel springs.Core can be easily removable and interchangeable to allow for maximum flexibility in the installation, maintenance and damper adjustment.4. Dampers can be installed so as to adjust airflow
Usage:
It is used for supply and extract air applications for bathrooms kitchens and external walls of the buildings. It generally are widely used for air outlet of air conditioner.
