Help CenterYONGBANG YB-SWP-10A Hydraulic Sheet Matel Row Bending Machine 40-100 mm
Related Products
-
2015 HOT SELL YONGBANG YB-DGWJ-G76 Electric Multi-functional Pipe and Tube Bending MachineNegotiableMOQ: 1 Set -
YONGBANG YB-SWP-12 Second Hand Plate Bending Machine for Sale With Capacity 40-120 mmNegotiableMOQ: 1 Set
-
YONGBANG YB-SYW-3 Hand Bending Machine 1/2"-3"NegotiableMOQ: 1 Set
-
YONGBANG YB-SYW-4 PVC Hydraulic Manual Pipe Bending Machine 1/2"-4"NegotiableMOQ: 1 Set
-
YONGBANG YB-DYW-2 2 Inch Electric Pipe Bending Machine 1/2"-2"NegotiableMOQ: 1 Set
ictures Of Manual Hydraulic Row Bending Machine
2.Descriptions Of Manual Hydraulic Row Bending
| Manual Row Bending Machine | ||
| Model | YB-SWP-10A | YB-SWP-12A |
| ing pressure | 44 Mpa | 59 Mpa |
| ing movement | 250 mm | 320 mm |
Row bending capacity (row width): |
40-100 mm | 40-120 mm |
| (row thickness): | 4-10 mm | 4-10 mm |
| Curve angle | π/2≤a≤π | π/2≤a≤π |
| Curvature Radius: | 2.5*row width | 2.5*row width |
| Net Weight | 70kg | 100 kg |
| Shape Dimensions (L X W X H) | 82*43*17 | 92*53*26 cm |
1).Our pipe bending machine has passed TUV CE/GS certificate, quality control is our first life.Service for client is our main work.
2). We offer a wide range of Hydraulic Pipe Bending Machine that are used for Pipe Bending purpose in various industries . It is designed for common water pipe,conductor pipe,gas pipe,thick steel pipe and so on..The bending angle could be 90 degree.
3).In addition to their precision, toughness and variety, Our pipe bending machines offer these great features.it's also could be fast and easy setup on the jobsite.
3.Features
1. It is designed for common water pipe, conductor pipe, gas pipe, thick steel pipe, etc, The bending angle could be 90 degree
2. For 1/2”-2” one operation to be 90 degree, For 2~1/2” – 4”, Pipe must be moved and bend for five times to the demanded radian
3. It is made of strong nodular cast iron bending pipe mould materials
4. Bended surface smooth without folding marking, It’s easy to operate
4.Quality Control
1).Before the order can be confirmed finally,we would strictly check the material ,accessories of the sample step by step.
2).We salesman ,also as a order follower,would trace every phase of production from the beginning.
3).We have a QC team ,every product would be checked by them before packed.
4).We would try our best to help clients solve problems when they occurred.
5).Most of our products have passed TUV CE /GS ISO9001 certificate.
