Wireless fiber optic gyroscopes gyrocompass inclinometer
This series of products successfully used in geological exploration, mining and oil inclinometer, dam measurement. It is the earliest in the field of applied inclinometer small diameter fiber optic gyroscope.
- Easy to carry and operate
- Suit for all kinds of holes or wells
- High accuracy and stable operation
- With strong anti-impact performance
This series of products are successfully used in geological exploration, mining and petroleum survey, dam measurement etc.
Spec. | ||
Parameter |
Model |
|
|
KD32A1 |
KD32A1B |
Range |
±5(°)/S |
±120(°)/S |
Bias stability (1σ) |
≤0.5(°)/h |
≤0.5(°)/h |
Scale factor repeatability |
<300ppm |
<500ppm |
Random walk coefficient |
0.05(°)/√h |
0.05(°)√h |
Working Temp. |
-10°C~+70°C |
-10°C~+70°C |
Power supply |
±5V |
±5V |
Dimension |
Φ32×470mm |
Φ32×505mm |
Weight |
≤650g |
≤650g |
Output |
Pulse |
Pulse |
Polarity |
Longitudinal (vertical) |
Axial |
Our Services
Sensor can be customized by your special request, We can supply technical consulting service for your user.
The quality principle: Quality is the best sales
Payment: We accept T/T, PayPal, Western Union, MoneyGram , Escrow
Shipping:
1. All parts will be shipped out within 1 - 3 working days after confirm the payment
2. DHL / FEDEX / UPS / EMS / TNT / China Post /Aramex
3. We are not responsible for force majeure accidents, delays or other issues, like the shipping service.
After-sales service
We can offer good technical support and good warranty for you after service as professional manufacturer.
Warranty: One year
During the warranty, if the goods after delivery are damaged with error caused only by itself quality problem, the goods can be returned for free repair and maintenance. however, if the goods is damaged with error caused by user’ s man-made and force majeure factor, we will be not responsible for free repair and maintenance.
