YONGBANG YB-T60BWS-R 2-stroke 60HP Electric Start Outboard Motor With Power Tilt

YONGBANG YB-T60BWS-R 2-stroke 60HP Electric Start Outboard Motor With Power Tilt thumbnail-1
YONGBANG YB-T60BWS-R 2-stroke 60HP Electric Start Outboard Motor With Power Tilt photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Usage:
Boat
Fuel:
Gasoline
Contact Supplier Request Quote Chat Now
Zhejiang Yongbang Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Boat
Fuel Gasoline
Stroke 2 Stroke
Cylinder Multi-cylinder
Cold Style Other, Water-cooled
Start Other, Electric Start, Electric starting control
Place of Origin Zhejiang, China
Brand Name YONGBANG
Model Number YB-T60BWS-R
Dimension(L*W*H) 713*364*1247mm
Weight 104kg
Certification CE
Warranty 18 months
After-sales Service Provided Overseas third-party support available
Product Description



1.Pictures of Outboard Motor

YONGBANG YB-T60BWS-R 2-stroke 60HP Electric Start Outboard Motor with Power Tilt







2.Descriptions Of Outboard Motor



                Item NO.

Parameter

measurement
 units

2-stroke

YB-T60BW(S/L)-R

Length

mm(in.)

713(28.1)

Width

mm(in.)

364(14.3)

Height

mm(in.)

S:1247(49.1)
L:1374(54.1)

Transom height

mm(in.)

S:394(15.5)
L:521(20.5)

Net Weight




BWS:104 BWL:106

Full throttle
operating range

r/min

4000-5000

Maximum output

KW(HP)@r/min

44.1(60)@5000

Idling speed

r/min

750~850

Cylinder quantity



3

Displacement

ml

849

Bore×Stroke

mm(in.)

72.0×69.5(2.83×2.74)

Control system




Tiller/operation

Starting System



BW:Electrical)

Gear positions



Forward-neutral-reverse

Gear ratio



2.33(28/12)

Trim and tilt system



Power tilt

Fuel tank volume

L(litre)

24

Engine fuel ratio



gasoline:engine oil=50:1

Engine oil

L(litre)

/

Gear oil

ml

430

Propeller spec

in

3-11 1/8"×13"-G



3.Features

Our company is professionally on producing OUTBOARD MOTORS and their SPARE PARTS.

All the main spare parts are produced and then assembled into hole engine on our own production line,

so we could do more to supply you goods of better quality with more competitive prices.


Till the end of  2009, we had invested over US $3, 000, 000 to develop outboard motors.

In 2010 the available styles are

4-stroke:2.5HP, 3.6HP,4HP, 5HP, 6HP,9.9HP, 15HP,20HP motors

2-stroke:2.5HP,2.6HP,3.5HP,3.6HP,4HP, 5HP, 6HP,8HP,9.8HP,9.9HP,12HP,15HP,30HP,40HP,60HP motors.


In 2015, our 2-strokes 60HP motor has been developing and available due to the succesee of available

motors.



Keeping the first-class quality, provide professional sevice and meanwhile to continuously develop new

products and improve quality, is our eternal aim and power. Every buyer’s satisfaction is our most

pleasure and success.


4.Quality Control

1).Before the order can be confirmed finally,we would strictly check the material  ,accessories of the sample step by step.

2).We salesman ,also as a order follower,would trace every phase of production from the beginning.

3).We have a QC team ,every product would be checked by them before packed.

4).We would try our best to help clients solve  problems when they occurred.

5).Most of our products have passed TUV CE /GS  ISO9001 certificate.



5.Inspection

YONGBANG YB-T60BWS-R 2-stroke 60HP Electric Start Outboard Motor with Power Tilt

6.Warehouse

YONGBANG YB-T60BWS-R 2-stroke 60HP Electric Start Outboard Motor with Power Tilt



Company Information



 1.Introduction

2.Our Company View

YONGBANG YB-T60BWS-R 2-stroke 60HP Electric Start Outboard Motor with Power Tilt

 3.Factory View

4.Our Team
