Specifications
Smart Home Wireless Home Automation system1. Wireless Zigbee
2. Frequency 2.4 Ghz
3. 95-240V AC,50Hz
4. user friendly
Smart Home Wireless Home Automation system
The technology of Smart Home Wireless Home Automation system is Wireless ZIGBEE
Specification of Smart Home Wireless Home Automation system
Zigbee protocol |
IEEE 802.15.4 |
Wired or Wireless |
Wireless |
Transmission Signal |
2.4Ghz, Zigbee / Wifi |
Supply Voltage |
AC 95-240 V; 50-60 Hz |
Date interface |
RS485; Dry contact, Zigbee |
Support software system |
IOS / Android |
Working Temperature |
-10 to 50 Degree |
How many rooms can be controlled |
256 rooms. ( 256 appliances in each room) |
Zigbee switches |
Touch screen electric resistance screen |
The advantages of Smart Home Wireless Home Automation system
<1> Support for multiple network topologies such as point-to-point,
<2> point-to-multipoint and mesh networks
<3> Low duty cycle – provides long battery life
<4> Low latency
<5 > Direct Sequence Spread Spectrum (DSSS)
<6> Up to 65,000 nodes per network
<7> 128-bit AES encryption for secure data connections
<8> Collision avoidance, retries and acknowledgements
Smart Home Wireless Home Automation system cover 3 parts:
1> controller parts: 2> controlled parts: 3> Coorinator.
The list of No 1> controller part:
TDWZ6402 |
Zigbee Touch Screen 2-way Scene Switch(Max 16 addresses per scene) |
TDWZ6406 |
Zigbee Touch Screen Wall Mount Centralized Controller with timing |
TDWZ6617 |
Zigbee Network Service Controller(Including IOS/Android Software) |
The list of No 2> Controlled part:
TDZ4202S |
Zigbee Smart Socket |
TDZ4203S |
Zigbee Touch Screen Fluorescent Lamp/Appliance Switch(Max1500W) |
TDZ4204S |
Zigbee Touch Screencrystal lamp Switch(Max1500W) |
TDZ4404S |
Zigbee Touch Screen 2-way Fluorescent Lamp/Appliance Switch |
TDZ4405S |
Zigbee Touch Screen 3-way Fluorescent Lamp/Appliance Switch |
TDZ4401S |
Zigbee Touch Screen Dimmer Switch |
TDZ4466S |
Zigbee one way Touch Screen Automatic Curtain Switch |
TDZ4468S |
Zigbee two way Touch Screen Automatic Curtain Switch |
TDZ4464S |
Zigbee Touch Screen Window Opener Switch |
TDZ4488S |
Zigbee Touch Screen Fingerprint door lock Switch |
TDZ4485S |
Zigbee Touch Screen Fresh Air Switch with three gear |
TDZ4462S |
Zigbee Touch Screen mechanical arm Switch |
TDZ4486S |
Zigbee Touch Screen Electric clothes airer Switch |
TDWZ6436 |
Zigbee IR Transceiver |
The list of No3> Coordinator
TDWZ6000S |
Coordinate |
TDWZ6001S |
Repeater |
Please check Smart Home Wireless Home Automation system to see the 3 parts:
The end device can be controlled by Smart Home Wireless Home Automation system
1> lighting system,
The controll ways can be realized by Smart Home Wireless Home Automation system
> 1 years warranty
> Products should be sent back in their original condition by buyer due to technical problems.
> Defective products should be returned in 7 days from the date of cargo receipt.
> All shipping costs of return are borne by buyer
> Kindly please contact us ASAP when meet problem on products.
Company profile:
We are a manufacturer and solution- maker of home automation over 10 years, have developed Wired PLC and Wirelss Zigbee home automation system
