Food Color Sorting Machine From Hefei Angelon Electronics
US$ 30,000 - 60,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
Angelon
Model Number:
A4L2S1C8-256
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Anhui, China
Brand Name
Angelon
Model Number
A4L2S1C8-256
After-sales Service Provided
Engineers available to service machinery overseas
Overview
Multifunction color sorting machine from Hefei Angelon Electronics is a mature and professional color sorting machine for many different materials, such as grains, nuts, vegetables, plastics and mineral etc.
- belt-type (double layer belts is available for removing defects with subtle color variation).
- high-resolution chromatic CCD sensor
- Passed ISO9001, CE, ETL and UL.
- Superior optical lens
- Intelligent shaker
- Air valves
REAL PICTURE of the product
REAL PICTURE of Scrap Plastics sorting result
Product Features
- High-Definition and high-sensitivity chromatic CCD image sensor, together with industrial wide-angle lens for accurate recognition, allows ultimate detection of defects and foreign materials. Be able to remove both lighter and darker colored defect simultaneously.
- Adopt the international first-class optical lens; the definition is within 0.07 mm, can recognize the subtle chromatic difference and tiny flaws. Two side camera is available for greater defect detection.
- Belt-type, avoids jumping in traditional chute-type color sorter and increases the output greatly.
- By using high-speed parallel data processing chip, real-time efficient image acquisition and processing system, the color separator working efficiency has been greatly improved.
- High quality image processing algorithm: advanced image processing technology is adopted, can effectively identify impurities as small as 0.1mm, which allows higher accuracy of color selecting and lower brought out.
- Unique LED lighting system, Equipped with LED light source makes Superior illumination to ensure high-definition image quality for better detection of defects, can meet up to 1000 kinds of color separation.
- Fan self-adaptive working temperature, ensure color separator in the high temperature environment also can work normally.
- Incomparable ejection accuracy, high frequency, long durability and long service life.
- Unique double layer belt-type design allows secondary sorting which make more precise sorting result, be able to remove the subtlest color variation.
- Special shaker ensures homogeneous material feeding and The right speed allows product stability on the sorting belt, which is essential for a proper sorting.
- Optimized ejection by air valves. Up to 512 air blast valves make a precise and fast rejection.
- Simple system set up, easy for clients to install. User-friendly computer interface, support saving varies of sorting mode for clients who needs to sort different materials. Low maintenance and no daily calibration required.
Technical Parameters
Type |
|
AL2K1C8-256 |
Channels |
|
256 |
Output(t/h) |
|
1.0-2.0 |
Sorting accuracy (%) |
|
>99.98 |
Optimized carryover rate(bad :good) |
|
>8/1 |
Voltage (V) |
|
~220(50Hz) |
Power of main machine (kW) |
|
2.0 |
Air Pressure (MPa) |
|
0.6~0.8 |
Dimension(L*W*H)(mm) |
|
3080*1820*2150 |
Weight (kg) |
|
1350 |
* NOTE: the parameters above is subject to change based on different materials.
Angelon offers sales and after-sales service in over 20 counties worldwide, and we are glad to expand our territory of sales and after-sales. No matter where you are, if you buy our products, we will surely provide excellent customer support.
Company Images
A warm welcome to every customer!
