Help CenterIR Far Infrared Ray Tunnel Dryer Machine
Related Products
Specifications
1. tunnel dryer machine2.Hyper pyretic heating tube
3.Design perfect hot blast system
4.CE approved
PCB tunnel dryer machine
Application:
Electronic products, nameplate button, silicone rubber, molding silicon,Hardware, all kinds of solvent ink and the drying of moisture bearing products
Main Features:
(1)The fever cabinet is Split-type design
(2Hyper pyretic heating tube, the drying temperature range is from 40 centigrade to 200 centigrade.
(3) Teflon conveyer belt mesh, Variable frequency motor drive, Frequency converter or electronic stepless speed regulation control and adjust the speed
(4)Design perfect hot blast system.
(5)We can provide electronic components according to customers’ requirements.
(6 )Superior temperature control electronic components, adjustable and controllable digital readout and PID function. The precision of temperature range is ±2°
(7)Install cooling motor in the discharge hole, cool and restore for the drying material.
Technical Parameters:
Model |
YB-IR850/T |
|
Model |
YB-IR750/T |
|
The width of Inner Container (mm) |
900 |
The width of Inner Container (mm) |
800 |
|
|
The width of transmission band(mm) |
850 |
The width of transmission band(mm) |
750 |
|
Dimension(W×H)(mm) |
1200×1600 |
Dimension(W×H)(mm) |
1100×1600 |
|
|
Drying Speed (meter/minute) |
0.1~8 |
Drying Speed (meter/minute) |
0.1~8 |
|
Temperature Range |
Normal Temperature-200°C |
Temperature Range |
Normal Temperature-200°C |
|
Power(V) |
380 |
Power(V) |
380 |
welcome your inquiry!we will try our best make everything best!!
