Place of Origin Zhejiang, China
Brand Name Chenxin
Model Number NMRV050
Gearing Arrangement Worm
Output Torque 22NM~~73NM
Rated Power 0.12kw~~0.75kw
Input Speed 1400rpm
Output Speed 14rpm--280rpm

Characteristics:

The Speed reducer motor features

(1) Large output torque

(2) Safe, reliable, economical and durable
(3) Stable transmission, quiet operation

(4) High heat-radiating efficiency, high carrying ability
(5) Combination of two single-step worm gear speed reducers, meeting the requirements of super speed ratio







gearbox oreder, buy gearbox, purchase gearbox

gearbox oreder, buy gearbox, purchase gearbox

Performance parameter for RV series worm gear speed reducer

Motor power  Model speed ratio output speed output toruqe

0.12kw

1400rpm

 NMRV050 40 35rpm 21.9N.M
NMRV050 50 28rpm 25.8N.M
NMRV050 60 24rpm 29.0N.M
NMRV050 80 18rpm 34.7N.M
NMRV050 100 14rpm 40.1N.M

0.18kw

1400rpm

 NMRV050 40 35rpm 32.0N.M
NMRV050 50 28rpm 38.0N.M
NMRV050 60 24rpm 34.0N.M
NMRV050 80 18rpm 53.0N.M
NMRV050 100 14rpm 55.0N.M

0.25kw

1400rpm

 NMRV050 5 280rpm  6.0N.M
NMRV050 7.5 186rpm 11.0N.M
NMRV050 10 140rpm 14.0N.M
NMRV050 15 94rpm 21.0N.M
NMRV050 20 70rpm 26.0N.M
NMRV050 25 56rpm 32.0N.M
NMRV050 30 47rpm 36.0N.M
NMRV050 40 35rpm 45.0N.M
NMRV050 50 28rpm 53.0N.M
NMRV050 60 24rpm 60.0N.M
NMRV050 80 18rpm 65.0N.M

0.37kw

1400rpm

 NMRV050 5 280rpm  9.0N.M
NMRV050 7.5 186rpm 16.0N.M
NMRV050 10 140rpm 21.0N.M
NMRV050 15 94rpm 31.0N.M
NMRV050 20 70rpm 39.0N.M
NMRV050 25 56rpm 47.0N.M
NMRV050 30 47rpm 54.0N.M
NMRV050 40 35rpm 66.0N.M
NMRV050 50 28rpm 73.0N.M

0.55kw

1400rpm

 NMRV050 5 280rpm 13.0N.M
NMRV050 7.5 186rpm 25.0N.M
NMRV050 10 140rpm 32.0N.M
NMRV050 15 94rpm 46.0N.M
NMRV050 20 70rpm 59.0N.M

0.75kw

1400rpm

 NMRV050 7.5 186rpm 34.0N.M
NMRV050 10 140rpm 44.0N.M
NMRV050 15 94rpm 63.0N.M







The speed reducer NMRV050 Accessories outline dimension

 gearbox oreder, buy gearbox, purchase gearbox



K1

G

KG

KH

R

NMRV050

100

 14

38.5

10

18







Speed reducer Size of Single Extension & Double extension

gearbox oreder, buy gearbox, purchase gearbox



D(h6)

B

B1

G1

L

L1

f

b1

 t1

NMRV050

25

50

53.5

92

153

199

M10

8

28







The NMRV050 speed reducer Motor - Double extension worm shaft

gearbox oreder, buy gearbox, purchase gearbox



G2

d(j6)

B

F

b1

t1

NMRV050

64

14

30

M6

5

16







The NMRV050 speed reducer Motor

gearbox oreder, buy gearbox, purchase gearbox



IEC Motor adapters

Model

PAM(IEC)

N

M

P

ration

Shaft:D

NMRV050

80B5

130

165

200

40

-

80B14

80

100

120

40

-

71B5

110

130

160

40

14

71B14

70

85

105

40

14

63B5

95

115

140

40

11





  The NMRV050 speed reducer Motor - Mounting positions

gearbox oreder, buy gearbox, purchase gearbox





Model RV025 030 040 050 063 075 090 110 130 150
Single unit versions

NMRV - fitted for motor flanged coupling,



NRV - with input shaft,



NMRV-E motor flanged coupling with worm extension shaft,



NRV-E with double extension worm shaft,
 Power 0.06----15KW
 Single unit reduction ratio  1:5 7.5 10 15 20 25 30 40 50 60 80 100
 Output torque  2.6---1195N.M
 Worm shaft  20CrMnTi with carburizing and quenching.The hardness of surface is 56-62HRC with carbonized layer 0.5-0.8mm
 Worm wheel  worm mandrel is HT250,and worm ring gear,ZQSn10-1
