Help Center100x60 Split Core Current Transformer
Related Products
-
80x80 Split Core Current TransformerUS$ 0.1 - 50MOQ: 100 Pieces -
80x50 Split Core Current TransformerUS$ 0.1 - 50MOQ: 100 Pieces
-
DBP Series-30x20 Split Core Current TransformerUS$ 0.1 - 50MOQ: 100 Pieces
-
High -current Zero-sequence Current TransformerUS$ 0.1 - 50MOQ: 100 Pieces
-
Needle Inserted Zero-sequence Current TransformerUS$ 0.1 - 50MOQ: 100 Pieces
Specification
Standard: GB1208 and IEC60044-1;
Rated Voltage: 0.66KV;
Operating Temperature: -15℃to 45℃;
Certificates: CE
Feature
Open type current transformer standard is mainly used in industrial city network, rural power network reconstruction project. The installation is convenient. They may be installed without opening any cable or bus-bar circuit. It does not affect the normal use of electricity customers, save a lot of manpower, material resources, financial resources , Improve the efficiency of transformation.
Dimensions (mm)
Parameter
1,Output:5A
2,Output:1A
Note:
- MOQ:1000PCS
- Delivery time:10-12 days or as per customer’s quantity
- Payment terms:50% deposit of total amount in advance and the rest after seeing B/L , T/T.
- Samples is free, but the fee of freight must be paid by recipient
- Port: Qingdao
- Package: As per customer’s requirements
- We will feel appreciated if you can provide the parameters of the product or the photo of the item.
- All products of the size,electrical performance can be designedaccording to customer requirement in R&D.
>>Main Products:
1. Current transformer
2. Planar Transformer
3. Encapsulated transformer
4. Toroidal transformer
5. High frequency transformer
6. Low frequency transformer
7. Other transformers, inductors etc.
<<<< The information and details of the products>>>>
>>Working
>>Application:
Switching power supplies, chargers, alarm system, TV and CRT monitor displays, UPS, VCD/DVD players, audio and visual equipment, OA machines, inverter.
