Help CenterDWC-22 CE Certificated Wood Chipper/wood Processor/diesel Wood Chipper Supplier's Choice
Related Products
Specifications
1. CE certificate2. high working efficiency
3. large cutting diameter
4. self feeding
5. best price and delivery time
Runshine diesel wood chipper DWC-22
Features:
1.CE certificate.
2.Yanmar diesel engine.
3.Hydraulic feeding.
4. 8″ Cutting diameter,
5.Easy discharge hood,
6. ball hitch and security chain
7. Discharge chute rotates 360 degrees.
8. self feeding design
9. feeding speed adjustable
Technical Data:
Model |
DWC-22 |
|
Engine |
Item |
CY1115 diesel engine |
type |
Single cylinder, horizontal, four-stroke |
|
Combustion chamber type |
Direct Injection |
|
Cylinder diameter |
115mm |
|
Piston stroke |
115mm |
|
Piston displacement |
1.194L |
|
Piston average speed |
8.43m/s |
|
Compression ratio |
17.3 |
|
Rated power |
16.2KW/2200rpm |
|
Effective pressure |
740KPa |
|
Fuel consumption rate |
<245g/KW.h |
|
Engine oil consumption |
<1.5g/KW.h |
|
Cooled style |
Water-cooled (evaporation) |
|
Start |
Electric start |
|
weight |
190kgs |
|
dimensions |
918x451x689mm |
|
Fuel |
Diesel 0# in summer, -10# or -20# in winter |
|
Chipper capacity |
150mm (Max. To 200mm) |
|
Flywheel diameter |
640mm |
|
flywheel weight |
85kgs |
|
Blades Numbers |
1 stationary blade, 2 rotary blades |
|
Feed Hopper inner Opening |
200 x 220mm |
|
Discharge Hood Height |
2000mm |
|
Rated RPM |
1080 |
|
Weight |
650kg |
|
Working efficiency |
7-11 cbm/h |
|
orders from dealers
we have dealer in European countries, Australia, South America and Japan.
factory & workshop
Contact me for more information on Facebook
......./wfrunshine
youtube----user---cnmachines
