Q1. How about quality stability?
Our products has a long service life up to 6-8 years when used properly.
Each set of hydraulic pump is fully tested on our hydraulic system to ensure product quality before we send them to our customers.
Q2.What about delivery time?
We offer 7 day production lead time. Normally we have most of the products in stock. 3-5 days is enough for delivery.
Our company specialize in manufacturing and supplying Rexroth series hydraulic pump and hydraulic motor.
Main products: A2F.A4V.A4VSO.A4VG.A4VTG.A4VSG,A6V,A7V.A8V.A10V.A10VSO.A10VG pump & spare parts, A2FM,A6VM,MCR03,MCR05 motor & spare parts.
Good quality, fast delivery and competitive pricing.
We use wooden case that can endure long time sea shipment. Our package can prevent products from damaged during shipment at maximum extent.
We also have professional forwarder who not only offer competitive price in freight but also provide fast custom clearance service to our customers.
1.We offer 24 hour online technical support to help our customer choose the pump they need and solve any techincal problem occured when using the pump.
2.We offer 18 month warranty time for our hydraulic pump. Should any quality problem occurs during warranty time, we will provide spare parts to our customers for charge free.
The A2FO--61 series hydraulic pumps are made
in china with higher quality and competitive cost.
This A2FO series pumps’ function and the overall size along with
all of the spare parts are as the same as the Original A2FO series pumps.
It can replace original A2FO series pumps very well.
The Fixed pumps A2FO--61 series pumps used for:
The Implement hydraulics of Construction Machinery: Concrete pumps, and so on...
Features of Rexroth A2FO hydraulic axial piston PUMP:
1. Bent axis design with fixed displacement
2. Completely interchangeable with original
3. For use as either pump or motor in hydrostatic drivers, in open of closed circuit
4. High performance rotary group with well-proven spherical control area with the advantages; self-centering low peripheral speed, high efficiency
5. Robust rolling bearings endure long service life
6. Drive shaft capable of adopting radial loading
7. Application: For engineering machinery, maritime boat and industrial machinery etc.
Technical Specifications
A2FO Series PUMP
Size |
|
|
| 5 | 10 | 12 | 16 | 23 | 28 | 32 | 45 | 56 | 63 | 80 |
Displacement |
| Vg | cm3 | 4.93 | 10.3 | 12 | 16 | 22.9 | 28.1 | 32 | 45.6 | 56.1 | 63 | 80.4 |
Speed |
| nmax | rpm | 5600 | 3150 | 3150 | 3150 | 2500 | 2500 | 2500 | 2240 | 2000 | 2000 | 1800 |
Flow | at nmax | qvmax | l/min | 27.6 | 32.4 | 37.8 | 50 | 57 | 70 | 80 | 102 | 112 | 126 | 144 |
Power | p=315bar | Pmax | kw | 14.5 | - | - | - | - | - | - | - | - | - | - |
Power | p=400bar | Pmax | kw | - | 21.6 | 25 | 34 | 38 | 47 | 53 | 68 | 75 | 84 | 96 |
Torque | p=315bar | Tmax | Nm | 24.7 | - | - | - | - | - | - | - | - | - | - |
Torque | p=400bar | Tmax | Nm | - | 65 | 76 | 101 | 145 | 178 | 203 | 290 | 356 | 400 | 511 |
Weight |
| m | Kg | 2.5 | 6 | 6 | 6 | 9.5 | 9.5 | 9.5 | 13.5 | 18 | 18 | 23 |
Size |
|
|
| 90 | 107 | 125 | 160 | 180 | 200 | 250 | 355 | 500 | 710 | 1000 |
Displacement |
| Vg | cm3 | 90 | 106.7 | 125 | 160.4 | 180 | 200 | 250 | 355 | 500 | 710 | 1000 |
Speed |
| nmax | rpm | 1800 | 1600 | 1600 | 1450 | 1450 | 1550 | 1500 | 1320 | 1200 | 1200 | 950 |
Flow | at Nmax | qvmax | l/min | 162 | 170 | 200 | 232 | 261 | 310 | 375 | 469 | 600 | 826 | 950 |
Power | p=350bar | Pmax | kw | - | - | - | - | - | - | 219 | 278 | 330 | 497 | 554 |
Power | p=400bar | Pmax | kw | 108 | 114 | 133 | 155 | 174 | 207 | - | - | - | - | - |
Torque | p=350bar | Tmax | Nm | - | - | - | - | - | - | 1393 | 1978 | 2785 | 3955 | 5570 |
Torque | p=400bar | Tmax | Nm | 572 | 678 | 795 | 1020 | 1145 | 1272 | - | - | - | - | - |
Weight |
| m | Kg | 23 | 32 | 32 | 45 | 45 | 66 | 73 | 110 | 155 | 322 | 336 |
Hydraulic testing system of hydraulic pump:
Each set of hydraulic pump is fully tested by our hydraulic system to ensure product 100 % quality before we send them to our customers.
Spray room of hydraulic pump and hydraulic motor:
Our spray room is dust free which ensures a perfect surface of our hydraulic pump and hydraulic motor.
Assembly line of hydraulic pump and hydraulic motor
Our assembly line is also dust-free which keeps the cleanliness of inner parts of our hydraulic pump and hyrdaulic motor.
Three-dimensional Measuring Instrument:
The three-dimension measuring instrument ensures our hydraulic pump and motor spare parts are the same to original ones.
Nitriding furnace of hydraulic pump and hydraulic motor:
The Nitriding funace ensures the hardness and abradability of our spare parts.
Hydraulic pump and motor spare parts stock
Machining center:
