2014 New type RXLS 20ton wood splitter with CE1.Warranty:18months
2.16t/20t/26t/30t/42t
3.shot deliver time
2014 New type RXLS 20ton wood splitter with CE
1.Can work horizontally or vertically, 12 seconds traving time.
2.Containe hydraulic oil tank and pump itself, trailer tow bar.
3.Gasoline engine log splitter, 6.5-15hp gasoline engine, 4 stroke, 4 cylinders.
4.DOT tires, EPA engine, CE certificate, competent to sell in the USA and European countries.
5.Φ500mm X 610mm(L) log capacity with steel log cradle to stabilize cutting position .
6.Easy to instal and operate, competitive price, long time warranty, enough spare parts
provided.
TECHNICAL SPECIFICATION | ||||||||
Model | LS20T/610H/V-BSD-E | LS26T/610H/V-BSD-E | LS30T/610H/V-BSD-E | LS37T/610H/V-BSD-E | LS42T/610H/V-BSD-E | |||
Description | Diesel engine driven, horizontal or vertical, Electric start | |||||||
Motive power | 6HP | 9.5HP | 9.5HP | 13HP | 13HP | |||
Battery | 12V/36mAh |
|
| |||||
Max. split force | 20tons | 26tons | 30tons | 37tons | 42tons | |||
Max split size | 500mm X 610mm(L) | |||||||
Hydraulic oil | 27L |
|
| |||||
Oil cylinder diameter | 4inch | 4.5inch | 5inch | 5.5inch | 5.5inch | |||
Travel time | 14 seconds | |||||||
Pump | 11GPM | 11GPM | 16GPM | 16GPM | 16GPM | |||
N.W./ G.W. | 252/262kgs | 255/265kgs | 270/280kgs | 290/310kgs | 290/310kgs | |||
Packing Method | 1pc./ steel pallet | |||||||
Container Quantity | 40pcs. for 20'FCL | |||||||
Warranty | 12months since B/L date | |||||||
Packing dimensions | 2250L*580W*540H mm | |||||||
About us: Our company is world famous leading manufacture of wood working mahcinery, our customers all over the world, especially in the Europe and Asia, North and South Amrica, India and Russia. Every year thousands of products for export. All machinery meets the CE requirements which applies to all European Union and EVA countries. Thanks for customers support and affirmation. Sincerely welcome your inquiry,visit and cooperation with us!
Package picture
Please email me to get quotation, more pictures, more informations
