Rebar Location Tester

FOB Price

US$ 2,000 - 2,150 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China		Brand Name	C-TECH
Model Number	T50

ncrete cover thickness
2. concrete member internal reinforcement position, rebar spacing

Rebar location/position detector:

Product usage:

Testing concrete cover thickness

Test concrete member internal reinforcement position, rebar spacing, reinforcement position distribution.

Estimation bar diameter

Detection of Cable and Plumbing pipe

Features

1. investigation depth could reach 180mm

2. Single comprehensive probe. No need to replace during test.

3. back-lit screen let instrument can be normal used under the condition of insufficient light

4. Machine software is complete .The report could be printed automatically connecting with computer

Work environment condition

No strong alternating electromagnetic field

No corrosive gas in the air.

Avoid larger vibration and impact

Avoid the LCD panel contact with sunlight directly

Main performance index

Number	Item		SPEC
1	Bar diameter application range(mm)		Φ6 – Φ50
2	maximum value permissible error of Bar diameter		≤±1
3	Protective layer thickness measuring range
	The first measuring range (mm)		6 - 90
	The second measuring range (mm)		7-180
4	The maximum error of reinforced protective layer thickness test value
	The first measuring range (mm)	The second measuring range (mm)
	6 - 59	7 - 79	≤±1
	60 - 69	80 - 119	≤±2
	70 -90	120 - 180	≤±4
5	Work environment condition
	Work temperature °C		-10 - +40
	relative humidity RH		< 90%
6	power supply mode		Alkaline cell X 6
