Grandway Rack Mount PLC Splitter

Name: Grandway Rack Mount PLC Splitter
Brand: F2H, Grandway
SKU: 104076573

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

F2H, Grandway

Model Number:

Rack mount Splitter

Shanghai Grandway Telecom Tech. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name F2H, Grandway

Model Number Rack mount Splitter

Specifications

Grandway Rack Mount PLC Splitter
1.Compact desigh
2.Low insertion loss and low PDL
3.High reliability

Grandway Rack Mount PLC Splitter

Description

1U rack mount splitter's dimension can bu customized based on customers' requirements, it can be placed into ODF to process the standard operation.

Features

Applications

Specifications

1×N(N>2)PLCS(With connector) Optical parameters:

parameters			1×4	1×8		1×16		1×32		1×64
1	Operation wavelength(nm)		1260~1650
2	Insertion loss(dB)	Max	7.7		11.0		14.0		17.2		31.3
3	Return loss(dB)	Max	0.6		0.8		1.2		1.5		2.0
4	Return loss(dB)	APC min	55		55		55		55		55
		UPC min	50		50		50		50		50
5	PLD(dB)	Max	0.2		0.3		0.3		0.3		0.3
6	Directivity(dB)	Min	55		55		55		55		55
7	Pigtail length(m)		1.0(±0.1) or customer specified
8	Fiber type		SMF-28ewith 3mm cable or cusomization
9	Operation temperature(°C)		-20~65
10	Storage temperature(°C)		-40~85
11	Dimension (L×W×H) (mm)		483×200×1U/483×200×2U/customization

Note: All measurement were done at room temperature and specification include connectors.

2×N(N>2)PLCS(With connector) Optical parameters:

parameters			2×4	2×8		2×16		2×32		2×64
1	Operation wavelength(nm)		1260~1650
2	Insertion loss(dB)	Max	8.1		11.5		14.5		17.8		21.8
3	Return loss(dB)	Max	1.2		1.5		1.8		2.0		2.0
4	Return loss(dB)	APC min	55		55		55		55		55
		UPC min	50		50		50		50		50
5	PLD(dB)	Max	0.2		0.3		0.4		0.4		0.4
6	Directivity(dB)	Min	55		55		55		55		55
7	Pigtail length(m)		1.0(±0.1) or customer specified
8	Fiber type		SMF-28ewith 3mm cable or cusomization
9	Operation temperature(°C)		-20~65
10	Storage temperature(°C)		-40~85
11	Dimension (L×W×H) (mm)		483×200×1U/483×200×2U/customization
