Specifications
RV-7028M bluetooth rear view mirror hands free car kitWith USB/SD MP3/MP4 playback
RV-7028M bluetooth rear view mirror hands free car kit
Monitor Spec:
7" LCD MIRROR MONITOR
Ratio: 16:9 /4:3
Pixel: 480*234
System: PAL/NTSC auto switch
Video input: 2 way
Audio input: 1 way
Backup: V2 auto reverse
View angle: U/D/L/R
Adjustable image brightness/color/contrast
built-in speaker
Built-in USB/SD JPEG/MP3/MP4 playback
Built-in Bluetooth handfree
With remote control and OSD menu
Power supply: DC11-32V
Current: 0.7A
Luminance: 300-400/m2
Operating temp.:-10°C ~ 60°C
Device size:171*125*19mm(W/H/D)
weight: 550g
Back up camera:
Image Sensors: 1/4" /1/3" Sharp CCD
TV System:PAL / NTSC
waterproof rate:Ip67
Effective Pixels:628x582 pixels / 656×492 pixels
Resolution:420TV lines
Minimum Illumination:1.0Lux / F1.2
Pin Lens:f=3.6mm / F = 2.0
Lens Angle:120°
Vertical Sync. Frequency:50Hz / 60Hz
Video Output:1.0vp-p, 75Ohm
Power Supply:DC12V
Current Consumption:≤200mA
Electronic Shutter:1/60 ~ 1/10,000 Seconds
Gamma Consumption:0.45
S/N Ratio:Better than 48Db
Scanning System:2:1Interlace
Operating Temperature:-20°C~70°C ,RH95% MAX
Storage Temperature:-40°C~85°C ,RH95% MAX
Package included:
7inch DIGITAL LCD MIRROR monitor x 1
Remote control x 1
Stand bracket x 1
1/4" Sharp CCD bus camera x 1
0.8M aviation connection cable x 1
20m waterproof aviation connection cable x 1
mirror monitor with bluetooth, USB/SD playback optional
