Help CenterTOPFAME RV-400A 4" Digital LCD Monitor ce Rohs Car Rear View System With Night Vision Camera
Related Products
-
RV-7000 7inch Heavy Duty Reversing Camera SystemNegotiableMOQ: 10 Units -
RV-7400V-4 Intelligent Car Reverse Parking Sensor System With 4-split Screen Monitor for Heavy Duty VechiclesNegotiableMOQ: 10 Sets
-
RV-7002V-4 7 Inch Car Rear View Camera System With 4-split Screen Monitor for Heavy Duty VehiclesUS$ 1 - 56MOQ: 10 Sets
-
RV-7400V 7 Inch Car Rear View System With LCD Monitor+backup Camera for Truck/VansNegotiableMOQ: 10 Sets
-
TOPFAME RV-7300V 7 Inch Color Night Vision ir Car Rear View SystemUS$ 1 - 180MOQ: 10 Sets
Specifications
RV-400A 4" digital LCD monitor ce rohs car rear view system4 inch digital rearview monitor
120 field view camera
TOPFAME RV-400A 4" digital LCD monitor ce rohs car rear view system with night vision camera
4inch digital LCD monitor
Resolution: 640(h) x RGB x 480(v)
Visible Area : 96 x 54mm
TV system: PAL/NTSC auto-switch
Power:DC 11-32V 1-3W
Auto save power function
Brightness and contrast adjust button
Ratio: 16:9
Video input: VI/V2 (V2 auto reverse)
Operation Temp.: -5°C- +50°C
Storage Temp.:-20°C - +60°C
Color: black
Display: black screen when no signal input
Dimension(L)*(H)*(D): 120*76*16MM
Net weight: 130g
Back up camera
Image Sensors: Sharp CCD, OV7950 /OV7949
TV System:PAL / NTSC
waterproof rate:Ip67
Effective Pixels:628x582 pixels / 656×492 pixels
Resolution:420TV lines
Minimum Illumination:1.0Lux / F1.2
Pin Lens:f=2.4mm / F = 2.0
Lens Angle:120°
Vertical Sync. Frequency:60Hz
Video Output:1.0vp-p, 75Ohm
Power Supply:DC12V
Current Consumption:≤120mA
Electronic Shutter:1/60 ~ 1/10,000 Seconds
Gamma Consumption:0.45
S/N Ratio:Better than 48Db
Scanning System:2:1Interlace
Operating Temperature:-20°C~70°C ,RH95% MAX
Storage Temperature:-40°C~85°C ,RH95% MAX
Package Included:
4inch digital LCD monitor x 1
Color CMOS/CCD camera x 1
8M/15M/20M video cable x 1
