Specifications
Explosion proof cameraCgrade EX-proof, night vision, waterproof
Explosion proof mark: ExdIICT6
Ideal for oil tank truck
TOPFAME EX-02 Anti-explosion camera, explosion proof camera for oil tank truck, etc.
C grade Ex-proof,true color 420TVline,infrared light auto
work in 15meters distance,
2.8mm/3.6mm/4mm/6mm lens optional
aluminum alloy material,protection level IP66,
small size, less weight and could be used in special place
which has limit space and weight requirements,such
as:oil tank truck,oil adding machine,small
warehouse,explosion -proof lift etc.
The explosion-proof performance accord with GB3836.1-2000 <<Electrical apparatus use general requirements:part1,which used under explosive gas atmospheres environment>>,GB3836.2-2000<< use explosion-proof electrical equipment under explosive gas environment : part 2 Exd explosion proof "d" >> standard and make Exd explosion proof structure.
Use unique special explosion proof glass, high light flux rate,avoid infrared light spot
Nanometer invisible features, rain wiper functions,non-stick water,non-stick oil,Exclusion of dust
All in one aluminum alloy structure,surface coated processing technology,explosion proof,
Avoid dust,water proof, little sizes for easily install,less weight for transportation
Work environments : Chemical industry,oil,steel,iron,Military project,medicine,mine,oil warehouse,ship,oil drilling platform,gas station,Production of fireworks and firecrackers,food Processing and storage.
Specification
model/signal type |
EX-02 PAL/NTSC |
Ex mark |
ExdIICT6 |
Protection grade |
IP66 |
connection type |
composite cable output |
Image sensor |
1/3"SONY Super HAD CCD |
resolution |
480/540/650/700 TVLine |
Min illumination |
0Lux |
Infrared invisible distance |
15 meter |
Infrared switch |
Infrared light automatic on(infrared light on when light sum less than 0Lux) |
lens |
2/4/6/8mm |
Work voltage |
DC12V |
Work current |
≤500mA |
Noise ratio |
>50dB |
Environment temperature |
-25°C~+70°C |
Atmosphere pressure |
86~106KPa |
Relative humility |
≤95%RH(+25°C) |
dimensions |
119mm ×108 mm(Length) |
Cable outlet specifications |
G 1/2" |
weight |
≤1.7Kg |
