Home > Products > LED Curtain Series > Most Popularly New Invention Product P12.5 SMD Flexible Indoor Full Color Led Display Screen Soft Led Curtain

Most Popularly New Invention Product P12.5 SMD Flexible Indoor Full Color Led Display Screen Soft Led Curtain

FOB Price

Negotiable / Unit

10 Units(Min. Order)

Port guang zhou
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	charming
Model Number	COL.PI.125.1000	Usage	Outdoor
Tube Chip Color	Full Color	Display Function	Video
Pixels	Other, 12.5	Screen Dimension	L300*H900mm

Product Description

Specification:
Type Number	COL.PI.125.1000/1003	Unit module composition	L1×H6 moudle
Pixel pitch(MM)	12.5	Unit module pixel	L24×H72 dot
LED Standard	SMD3528	Max.power consumption	96W
Pixel composition	3 IN 1	Module material	PC
Pixel density(dot/m2)	6400	Protection level	IP 65
Demensions(mm)	L300*W150	Viewing angle	110°
Module Power	6W	Working temperature	-20℃~+50℃
Module resolution(L×W)	24×12	Working humidity	10%~90% RH
Scan mode	1/6	Life span	≥30,000 hours
Grey	65536	Working voltage	AC 220 V / (110V) ±15% , 47~63 HZ
Refresh rate(Hz)	≥2000	Signal transfer	Lan cable
Brightness (CD/m2)	1000	Control system	LED FLASH Computer Control System
Best viewing distance(M)	12	Computer platform	Windows XP,Windows 7
Unit module dimension	L300×H900mm	Video Sources available	DVD, VCD, VCR, TV, camera with PAL/NSTC
Control case size	535×200×150mm	Electric case product code	COL.C.006.1011
Control area	L4×H3string/L2×H6string	Control pixel	L96×H216dot/L48×H432 dot
Control area dimension(mm)	W1200×H2700MM/W600×H5400MM	Control case max.power	1200W
Effetive control distance	≤ 100 M (by LAN) , ≥ 100 M (by fiber optic with multi-module or single module
