Specifications
black and white Ultrasound1.10.1'' LED screen; easy to operate and carry;
2.for hospital
3.made in China
Portable black and white Ultrasound ISO CE FDA
Model: Berry B-1
Black and white Ultrasound adopt the latest techniques to realize a crystal clear, stable and high resolution imaging function. Laptop design makes it easier to carry and operate. And it can be used for examination and diagnosis of abdominal (Transvaginal) organs, and other small parts with different probe. It is applicable for both people and animals.
Technical Specification
Technical Specification |
||
Screen |
10.1″ LED |
|
Weight |
1.5 kg |
|
Probe connectors |
1 |
|
Display Mode |
B,2B,BM,M,4B |
|
Scanning Methods |
Convex ,Linear |
|
Scanning speed |
2s, 4s, 6s, 8s are provided in the mode of M or BM mode |
|
Image processing |
Multi-level magnification |
|
Depth upgrade |
|
|
Zoom and scroll control |
|
|
3-segment TGC adjustment |
|
|
256 gray scale |
||
Frame correlation and line correlation |
||
Up/down, left/right, black/white reversing |
||
Edge enhancement |
||
Dynamic filtering |
||
Wide dynamic range |
||
Total gain, brightness, contrast, and angle adjustment |
||
Image output |
USB disk or SD card |
|
USB 2.0 interface ensures real-time image transfer to PC |
||
Cine Loop |
256 frames , playback selectable |
|
Permanent image storage |
1024 frames in flash memory |
|
measurement |
Distance, perimeter, area, volume, angle |
|
Heart rate |
|
|
Pregnant week, fetal weight etc. |
|
|
Body marks |
≥40 |
|
Note |
Hospital information |
|
Patient information |
|
|
Date, Time |
|
|
Image annotations etc. |
|
|
Pseudo color processor available |
|
|
Supporting USB mouse action, Printing function.,Power save mode. |
|
|
Probe Specification
Frequency |
3.5 MHz±15% |
3.5 MHz±15% |
6.5MHz±15% |
7.5MHz±15% |
Probe type |
R= 60mm convex |
R= 20mm convex |
R=13mm convex |
L=40mm linear |
Scanning depth |
≥ 160 |
≥ 140 |
≥ 40 |
≥ 50 |
Axial resolution, mm |
≤3 (Depth≤80) ≤4 (80< Depth ≤130) |
≤3 (Depth≤80) ≤4 (80< Depth ≤130) |
≤2 (Depth ≤30) |
≤2 (Depth ≤40) |
Radial resolution, mm |
≤2 ( Depth ≤80) ≤3 (80< Depth ≤130) |
≤2 ( Depth ≤80) |
≤1 ( Depth ≤40) |
≤1 ( Depth ≤50) |
Blind zone, mm |
≤5 |
≤7 |
≤4 |
≤3 |
Geometric positioning accuracy ,% |
≤15(Radial) ≤10(Axial) |
≤20(Radial) ≤10(Axial) |
≤10(Radial) ≤5(Axial) |
≤10(Radial) ≤5(Axial) |
Standard Configuration
Monitor |
1pc |
|
3.5MHz R60 convex probe ( Abdominal organs) |
1pc |
Options
Probe Type |
Application |
6.5MHz R13 Micro-convex Probe |
Transvaginal |
7.5MHz L40 Linear Probe |
Small parts |
3.5MHz R20 Micro-convex Probe |
Cardiac |
5.0MHz R20 Micro-convex Probe |
Cardiac |
Power information
Power supply |
AC 100~240V, 50/60Hz; |
Rechargeable lithium battery, one full charge can work for 2 hours. | |
Power consumption |
≤50VA
|
Requirements for environment
|
Operation |
Preservation |
Transportation |
Temperature |
5°C~ 40°C |
-5°C~40°C |
-30°C~55°C |
Humidity |
30%~80%, no condensation |
< 80%, no condensation |
≤95%, no condensation |
Atmospheric pressure |
86kPa~ 106kPa |
86kPa~ 106kPa |
50kPa~ 106kPa |
Image display
