Specifications
Automatic estimate malfunction and prompt message, helpul for the maintenanceST-8065 X-RAY MACHINE
FEATURE:
1. ALARM BY SOUNDS & LIGHT:ALARM BY SOUNDS AND LIGHT WHEN CONFORM TO CONDITION.
2. NETWORK INTERFACECOULD BE CONNECT LOCAL AREA NETWORK AND SUPPORT MULTI-TERMINAL CHECK BAGGAGE AT SAME TIMES
3. SAFETY RAYTRANSMIT RAY UNDER AUTOMATIC CONTROL, AVOIDS THE MISS
4. TURN OFF BY A KEY CONTROLTURN OFF THE MACHINE ONLY NEED ONE STEPREVOLVES THE KEY. THE EQUIPMENT AUTOMATIC SECURITY CLOSE-DOWN, DOES NOT NEED COMPLEX MANY STEPS, IS SIMPLER.
5. EAGLE-EYECOULD BE EXPEDIENTLY OBSERVING ENLARGEMENT AREA.
6. ESTIMATE MALFUNCTION BY SELFAUTOMATIC ESTIMATE MALFUNCTION AND PROMPT MESSAGE, HELPFUL FOR THE MAINTENANCE.
X-RAY GENERATOR:
ORIENTATION: VERTICALLY UPWARD
TUBE CURRENT: 0.4~0.7MAADJUSTABLE
ANODE VOLTAGE: 100~160 KV(ADJUSTABLE
ANGLE: 60°
GENERATOR COOLING/WORKING PERIODS SEALED OIL BATH WITH FORCED AIR/100
IMAGE PERFORMANCE SYSTEM:
X-RAY SENSOR: L TYPE PHOTO-DIODE ARRAY DETECTOR, 12BIT
MONITOR: HIGH RESOLUTION 17INCH COLOR LCD DISPLAY
COLOR QUALITY: 24 BIT REAL COLORS
EDGE ENHANCEMENT: OBJECT CONTOUR EDGE IS MORE DISTINCT
SUPER IMAGE ENHANCEMENT: IMAGE DETAIL IS MORE DISTINCT
HIGH PENETRATE STRENGTH DISPLAY: INCREASE BRIGHTNESS OF DARK AREA IN IMAGE TO DISPLAY OBJECT WHICH IS BEHIND HIGH ABSORPTIVITY MASS DISTINCTLY
LOW PENETRATE STRENGTH DISPLAY: INCREASE CONTRAST OF LOW ABSORPTIVITY MASS (EASY TO PENETRATE) TO DISPLAY IT DISTINCTLY
MAGNIFIER: FUNCTION OF PARTIAL ENLARGEMENT
BRIGHTENING/DIMMING: INCREASE BRIGHTNESS OF IMAGE/DECREASE BRICHTNESS OF IMAGE
IMAGE RECURRENCE: DISPLAY PREVIOUS TWENTY IMAGES AND PROCESS ANY ONE OF THEM
IMAGE RESTORATION: RESTORE IMAGE TO INITIAL STATUS AT THE TIME OF STOPPING CONVEYOR
IMAGE STORING: REAL TIME STORE ANY IMAGE AND PROCESS IT IN OPERATION STATUS
MULTI-ENERGY FUNCTION:
MULTI-ENERGY COLOR: DISPLAY ORGANIC MATERIAL FOR ORANGE, DISPLAY INORGANIC MATERIAL FOR BLUE, AND DISPLAY MIXTURE FOR GREEN
HIGH ENERGY/LOW ENERCY: SWITCH TO DISPLAY TWO ENERGY TYPE, HIGH ENERGY STANDS FOR METAL ETC., LOW ENERGE STANDS FOR NONMETALLIC
AUXILIAY FUNCTION FOR DRUGS & EXPLOSIVES: HELP TO DETECT SUCH DANGEROUS MATERIAL AS DRUGS & EXPLOSIVES ETC.
AUDIBLE & VISIBLE ALARM: GIVE SOUND AND VISIBLE SIGNAL WHEN CONFORMING TO CONDITION
OPERATING ENVIRONMENT:
STORAGE TEMPERATURE: -20ºC TO 60ºC
OPERATING TEMPERATURE: 0ºC TO 45ºC
RELATIVE HUMIDITY: 20 TO 95% NON-CONDENSING
SYSTEM POWER: 220 VAC (±10%) 50±3HZ
POWER WASTAGE 1.0 KW (MAX)
NOISE <65DB
