Wholesale Lock Plug Type AZ-7 Horizontal Limit Switch
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WEHOPE
Model Number:
AZ-7
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Wholesale FS Electric Foot Pedal SwitchNegotiableMOQ: 100 Pieces -
Website New Design FS Foot Pedal SwitchNegotiableMOQ: 100 Pieces
-
Aluminum Frame FS Foot Switch Pedal SupplierNegotiableMOQ: 100 Pieces
-
Standard of IEC337-1 and GB14048.5-2001Aluminum Frame Reversible FS Pedal SwitchNegotiableMOQ: 100 Pieces
-
China FS Wireless Foot SwitchNegotiableMOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
WEHOPE
Model Number
AZ-7
Protection Level
IP64
Operating Temperature
-10℃~+80℃ (with no icing)
Max. Current
5A
Max. Voltage
250V
Main technical parameters for Wholesale Alibaba lock plug type AZ-7 Horizontal Limit Switch
| Models | OF(Max.) | RF(Min.) | PT(Max.) | OT(Min.) | MD(Max.) | OP(mm) | FP | Weight(kg) |
| AZ-7100 | 600g | 100g | 2.0mm | 0.8mm | 0.8mm | 30.5±0.8 | 0.070 | |
| AZ-7110 | 600g | 100g | 2.0mm | 5.0mm | 0.8mm | 44±1.2 | 0.085 | |
| AZ-7310 | 600g | 100g | 2.0mm | 6.0mm | 0.8mm | 21.8±1.2 | 0.085 | |
| AZ-7311 AZ-7312 |
600g | 100g | 2.0mm | 6.0mm | 0.8mm | 33.3±1.2 | 0.090 | |
| AZ-7120 | 150g | 40g | 13.5mm | 4.0mm | 3.2mm | 25±1 | 35mm | 0.054 |
| AZ-7140 | 220g | 60g | 8.5mm | 2.5mm | 2.0mm | 25±1 | 32mm | 0.054 |
| AZ-7121 | 180g | 50g | 11.0mm | 3.0mm | 2.4mm | 40±1 | 0.057 | |
| AZ-7141 | 240g | 80g | 6.5mm | 2.0mm | 1.5mm | 40±1 | 46mm | 0.056 |
| AZ-7124 | 200g | 60g | 11mm | 3.0mm | 2.4mm | 50±1.2 | 0.062 | |
| AZ-7144 | 280g | 100g | 6.5mm | 2.0mm | 1.5mm | 50±1.2 | 56mm | 0.061 |
| AZ-7166 | 120g | 250mm | 11mm | 0.083 |
Characteristics Of Contact Module
| Rated operating characteristics | Inductive load: ~AC15,B300 (Ue=240V, Ie=1.5A) --DC-13,R300 (Ue=250V,Ie=0.1A) Resistive load:250V, 5A |
| Rated insulation voltage | Ui=500V, class of pollution is 3, comply with IEC 60947-1 Ui=300V, comply with UL508, CSA C22-2n°14 |
| Insulation sistance | 100MΩ above (megohmmeter of 500VDC) |
| Operating equency | Mechanical: maximum 240 times/min.; electrical: maximum 20 times/min. |
| Electrical life | 500,000 times |
| Contact resistance | Less than 15MΩ (initial value) |
Environmental Characteristics
| Normative reference |
Product | IEC60947-5-1, EN60947-5-1, UL508, CSAC22-2N°14 |
| Components | IEC60204-1, EN60204-1 | |
| Ambient temperature | Operation | -10~+80℃ |
| Storage | -40~+80℃ | |
| Vibration resistance | IEC60068-2-6 Comply with IEC60068-2-6 |
10-55Hz complex amplitude 1.5mm, misoperationwithin 1ms (in state of FP,TTP) |
| Shock resistance | IEC60068-2-27 Comply with IEC60068-2-27 |
Maximum 300m/s2, misoperation within 1ms (in state of FP, TTP) |
| Degree of protection |
IP54 | |
| Mechanical life | 10,000,000 times | |
| Operation speed | 0.01mm to 1m/sec (lock plug type) |
The detail of the Wholesale Alibaba lock plug type AZ-7 Horizontal Limit Switch
Characteristic/Application
1.Virous of actuators, the operation position is adjustable (such as AZ-7121);
2.Outer shell covered with intensive plastic, water-proof and oil-proof.
3.The mechanical strenth is better than TM type of micro swith, bear hitting.
