Specifications
1.Competitive price2.OEM /ODM
3.High quality
4.Attentive Service
5.Customization & Personalization
Technical Data
| Type | ZYM4-125 | ZYM4-250 | |
| Pole No. | 3 | 3 | |
| Rated current In(A) | 25-125 | 125-250 | |
| Rated working voltage Ue(V)(50/60Hz) | 500 | 600 | |
| Rated working voltage Ue --(V) | 250 | 250 | |
| Rated insulation voltage Ui --(V) | 500 | 690 | |
| Rated impulse voltage Uimp(kV) | 6 | 8 | |
| Utilisation category | A | A | |
|
Rated limited short-circuit breaking capacity Icu(kA) |
230/240V | 22 | 60 |
| 400/415V | 16 | 36 | |
| 440V | 10 | 30 | |
| 480/500V | 8 | 25 | |
| 600V | - | 20 | |
| 690V | - | 16 | |
| 250V | 16 | 36 | |
| Rated short-circuit breaking service capacity Ics(%Icu) | 100 | 100 | |
| Life(Open,close for a time) | Mechanical | 7000 | 7000 |
| Electrical | 1000 | 1000 | |
Application
ZYM4 series MCCB is applicable circuit of AC 50/60Hz,rated current 25-250A,for distribute energy of electricity & breaking circuit in normal conditions.The products conforms to IEC60947-2.
Product's advantage
1.our products have an excellent ratio between price and quality ,you can possess them by competitive price and high quality;
2.The fast and flexible production form aim at the customer require;
3.The deliveries exactly in accordance with customer orders
4.The fast transportation.
Order note
1,following items should be marked when ordering
2,product Name,model&Frame level
3,pole
4,Tripping characteristic and rated current
5,quantity
6,Ordering sample
mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp mccb 200amp
Packaging:
The packaging of the moulded case circuit breaker is standard export carton or according to your requirements.
Shipping:
normally ocean shipping
The delivery date of the moulded case circuit breaker is within 20-30 days after receiving payment.
Our service
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English
3.OEM&ODM, any your customized breakers we can help you to design.
4.Distributorship are offered for your unique design and some our current models
5.Protection of your sales area, ideas of design and all your private information
FAQ
Q 1. what's the payment term?
A. We accept TT, 30% deposit and 70% balance agaisnt copy of BL, Western
Union ,L/C is ok!
Q 2. how's the delivery time ?
A. usually it will take about 15~20 days for production
Q 3. tell me the standard of package?
A. For the small capacity, it use carton.
Q 4.Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q 5.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Q6. How about the transport?
A. If the number of goods is small we usually use TNT, TNT-DHL,EMS,DHL and some express you offered. If the number of the goods is big usually we use the FWD you offered. Either by sea or by air is OK.
Q7. What is the different between HOUPU and WEHOPE ?
A. HOUPU is my company name and the WEHOPE is brand name of our products.
