Help CenterMain Product ZYC16-63 Circuit Breaker Accessories With Professional,push Button Circuit Breaker
Related Products
-
Wehope HDP Type Automatic Voltage Regulator PriceUS$ 1.5 - 7MOQ: 500 Pieces -
DZ47 MCB Over/under Voltage Release,circuit Breaker Accessories ManufacturerUS$ 1.5 - 7MOQ: 500 Pieces
-
Main Products Full-Automatic Over and Under Voltage Power ProtectorUS$ 1.5 - 7MOQ: 500 Pieces
-
Circuit Breaker Accessories DC24V-48V MX+OF Shunt Tripper,circuit Breaker AuxiliaryUS$ 1.5 - 7MOQ: 500 Pieces
-
MX&MX+OF Circuit Breaker Auxiliary,alert SwitchUS$ 1.2 - 2.2MOQ: 500 Pieces
Specifications
1.Competitive price2.OEM /ODM
3.High quality
4.Attentive Service
5.Customization & Personalization
F3 Auxiliary Contact
Contact capacity:
AC:Un=415V In=3A
Un=240V In=6A
DC:Un=125V In=1A
Un=48V In=2A
Un=24V In=6A
Dielectric strength: 2kV/1min
Electro-mechanical endurance:≥5000
Mounted on the left side of the MCB ZYC 16-63, indicating ON , OFF status of combined MCB.
Terminal connection height: H1=31mm H2=16mm H3=1.3mm
S3 Shunt Tripper
Rated insulating voltage(Ui): 500V
Rated power voltage (Us): AC 400, 230, 125V
Operate voltage range: 70~100% Us
AC: 3A/400V
AC: 6A/230V
AC: 9A/125V
Dielectric strength: 2kV/1min
Electro-mechanical endurance: ≥4000
Mounting on the right side of MCB/RCBO, used to trip the combined MCB/RCBO by remote controlling device.
Terminal connection height: 19mm
Product's advantage
1.our products have an excellent ratio between price and quality ,you can possess them by competitive price and high quality;
2.The fast and flexible production form aim at the customer require;
3.The deliveries exactly in accordance with customer orders
4.The fast transportation.
Order note
1,following items should be marked when ordering
2,product Name,model&Frame level
3,pole
4,Tripping characteristic and rated current
5,quantity
6,Ordering sample
The detail of ZYC16-63 electric switch and accessories , push button circuit breaker
Packaging:
The packaging of the push button circuit breaker is standard export carton or according to your requirements.
Shipping:
normally ocean shipping
The delivery date of the push button circuit breaker is within 20-30 days after receiving payment.
Our service
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English.
3.OEM&ODM, any your customized breakers we can help you to design.
4.Distributorship are offered for your unique design and some our current models.
5.Protection of your sales area, ideas of design and all your private information.
push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker push button circuit breaker
remote control circuit breaker remote control circuit breaker remote control circuit breaker remote control circuit breaker
FAQ
Q 1. what's the payment term?
A. We accept TT, 30% deposit and 70% balance agaisnt copy of BL, Western
Union ,L/C is ok!
Q 2. how's the delivery time ?
A. usually it will take about 15~20 days for production
Q 3. tell me the standard of package?
A. For the small capacity, it use carton.
Q 4.Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q 5.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Q6. How about the transport?
A. If the number of goods is small we usually use TNT, TNT-DHL,EMS,DHL and some express you offered. If the number of the goods is big usually we use the FWD you offered. Either by sea or by air is OK.
Q7. What is the different between HOUPU and WEHOPE ?
A. HOUPU is my company name and the WEHOPE is brand name of our products.
