Specifications
GSHP 185-3700 R22Cooling capacity: 185-3700 kW
Heating capacity: 207-4144 kW
33 sizes available ranging from 207 kW to 4144 kW
heating capacity.
Reusable: using solar energy stored in earth as cooling
& heating source.
Great environmental and economic benefit: no boiler or
cooling tower; less space, less CO2 and less initial
investment.
Acting as multi-function unit such as cooling, heating,
sanitary hot water separately or simultaneously.
Wide application as hotel, apartment, villa, factory,
shopping center, office building, school, etc.
Semi-hermetic screw compressor for mod. 185÷3700.
Each compressor is equipped with a crankcase heater
and a thermal overload cut-out; the screw compressor
is also complete with a built-in electronic protection with
temperature sensor located directly in the motor
winding and on the discharge line.
The refrigerant circuit is complete with sight glass, filter
drier, high and low pressure gauges, solenoid valve,
direct expansion valve, high and low pressure switch.
Shell and tube dry expansion type condenser, factory
insulated with flexible close cell material.
Shell and tube type evaporator, factory insulated with
flexible close cell material.
The electric panel consists of compressor breaker,
compressor contactor, phase sequence relay, control
circuit breaker, microprocessor control with function
display.
LCD display, touch screen control panel as standard.
Automatic operation dramatically reducing maintenance
cost thanks to reliable microprocessor system.
For the units with semi-hermetic screw compressor, an
infinitely variable capacity control system that is capable
of exactly matching the demand requirement of the
system is to be supplied. This system is to provide
precise and stable control of supply water temperature
over the complete range of operating conditions.
OPTIONAL
Electronic expansion valve.
Desuperheater as optional.
Electronic controller with BMS system.
Low noise compressor cabinet or outside full cover
Channel Steel base
