Water Chilled Fan Coil Units (4 pipe and 3+1rows)
Negotiable
/ Set
1 Set(Min.Order)
- 1 Set / Sets per Month
- Tianjin
- T/T
You May Like
- Vibration Absorber, Eliminator Shock Absorber, refrigeration part, air conditioner part
- AC motor start capacitor, compressor capacitor, refrigeration capacitor
- Quick coupler QC-LM QC-HM, refrigeration part
- Quick coupler QC-L QC-H, refrigeration part
- Quick coupler QC-15AL QC-15AH, refrigeration part
- Quick coupler QC-12L QC-12H, refrigeration part QC-12L/H
Product Details
Place of Origin: | Shandong, China | Brand Name: | Bright | Model Number: | GSHP 480MJS-3800MJS |
Type: | Air Conditioning |
Product Description
Specifications
FP 3.4 - 20.4
Panels and frame are made of galvanized steel, properly
punched and punched for fixing both accessories and the
unit itself, either to wall (vertical version) or ceiling
(horizontal version).
HEATING COIL
The coils are made of seamless tubes expanded into
aluminum fins in continuous block. The connections have
brass headers with female fittings and provided with easily
accessible vent and drainage valve.
FAN DECK
The fan decks are composed of double suction centrifugal
fans with aluminum impellers and 3-speed fan motors. Each
fan motor assembly is dynamically balanced.
FILTER
The easily removable filter is made of filtering honeycomb
polypropylene fabric and supported by an aluminum or
plastic frame.
DRIP TRAY
The drip trays are made from sheet metal treated with
polyester powder coating to ensure total resistance to
atmospheric agents. The “L” type tray makes the units
suitable for both vertical and horizontal installation.
ELECTRICAL CONNECTION BOX
All electric wires are connected to enclosed electrical
terminal block, situated on the opposite side to the water
connections.
DECORATIVE CABINET
The decorative cabinet has a modern design that blends in
with any environment. It’s made from galvanized steel
treated with polyester powder coating to ensure total
resistance to rust, corrosion, chemical agents, aliphatic
solvents and alcohols.
The discharge grille and supporting legs are made of ABS
materials.
ON-BOARD THERMOSTART
Mechanical type for two pipe system exposed version use,
working mode selection (OFF-Heating-Cooling), ventilation
(HIGH-MED-LOW) and room temperature setting.
OPTIONAL
Condensation tray (water connection area)
Different type thermostats with more advanced functions
High external static pressure 30Pa and 50Pa
