Specifications
Multimedia central control systems are widely used for multimedia classroom, auditoria, command and control center etc.Multimedia
integration control system consists of four parts:
1. User Interface;
2. Central control console;
3. All types of control ports;
4. Controlled equipment.
Multimedia integration control systems are widely used for multimedia classroom, auditoria, command and control center and so on. Users can use push-button control panel, computer monitors, touch screen and wireless remote control and other equipment through the computer and central control system software to control the projector, Visual Presenter, DVD players, video recorders, amplifier, microphone, laptop, electric screens, electric curtains, lighting and other equipment.
Specification:
HS-360A | |
Audio/video signal parts | |
Composite video input |
2 |
RGB/HV input |
2 |
Stereo audio input |
4 |
Composite video output |
1 |
RGB/HV output |
2 |
Stereo audio output |
2 |
Video signal bandwidth |
450MHZ |
RGB signal bandwidth |
250MHZ |
Audio signal bandwidth |
15MHZ |
Video signal extent |
≤2Vpp |
Audio signal extent |
≤2Vpp |
RGB signal extent |
≤1Vpp |
Signal control parts | |
10 input port |
Optional |
Infrared remote control output |
3 outputs |
Electromotion curtain control port |
1 jack |
Power control port |
1 jack |
RS232 communicate port |
1 jack |
Extend communicate port |
1 jack |
Editor bunch port |
1 jack |
Remote control distance |
12M |
The whole part | |
Power range |
164-260AC V |
power |
9W |
Mainframe size |
240mm × 120mm × 90mm |
Open panel size |
260mm × 140mm × 1.2mm |
Accessories |
Remote control, lines, manual . |
