INTRODUCTION
With the tried and tested principle of stacking and moving closer together, the new Combiparker-L595 creates even more space. With up to 8 levels on top of each other and up to 5 grids next to each other, this system accommodates up to 31 parking spaces.
Vehicles are parked in parking levels with the aid of adjustable sliding carrier units. In every second grid, transport lifts ensure the lifting and lowering of vehicles. These grids also serve as the entrances and exits.
SPECIFICATION
- Compact parking on up to 8 levels above ground
- Variable arrangement of 2-5 grids beside one another
- For different car heights
- Platform loading up to 2600 kg
- A combination of stacking and moving cars closer together
- Independent parking
- Cost-effective comb technology
- High level of operating and functional safety
- Easy operation with transponder chip
- Also suitable for car service centre, car dealers, car rent
PARAMETER
Quick Details
Type:Parking system Height (mm): 5300-5950 Width (mm): 2600
Place of Origin: Henan, China (Mainland) Brand Name: DMAC Model: CombParker-L595
Warranty: 10 Years Parking system type: Parking system Color: Optional
Technology: Germany
Detail | |
Brand |
DMAC |
Model |
Combiparker-L595 |
Type |
2-8 levels PLC control puzzle car parking system |
Weight of car |
1500kg-2500kg |
Lifting speed |
4.5m-8.2m/min |
Lifting motor power |
Sliding 0.2kw Lifting 2.2-3.7kw |
Power supply |
380V/50HZ 3 Phase 5 Wires(customized according to user’s demand) |
Mode of drive |
Motor & Chain or steel rope |
Car position scanning |
Infrared ray |
Modes of operation |
Manual, IC card or Fingerprint |
Pallet material |
Galvanized corrugated plate |
Safeguard devices |
Whole protection and anti-fall safety hook |
Package |
Standard export package for automatic car parking system |
Warranty time |
10 years for structure and 12 months for electrical key parts |
Certificate |
CE & ISO90001 |
1. Are you a factory?
Yes, we are a professional manufacture to supply you the Automatic Car Parking System.
2. How long of the warranty?
The main motor & electrical device is one year, and main structure can be last for 30 years. (maintenance by our instruction)
3. Within the warranty, any measure to protect our benefit?
The quality assurance policy, it can guarantee you any damage caused by the quality problem.
4. Can we get any discount?
Sure, only your quantity is big enough. And if you want to be our agent in your local area, more discounts and promotion measures will be available to help you expand the parking business.
5. Do you have any engineers oversea available?
Once we make the order successfully, we will send our engineers to instruct your installation of the car parking system, and within our warranty period, if there are any quality problem, we can also send engineers to solve it free of charge.
