Rewinding Machine

Name: Rewinding Machine
Brand: WanJie
SKU: 103917331
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Application:

Food, Commodity, Medical, Other, Apparel, Food, Commodity, Medical, Machinery & Hardware, Apparel

Packaging Type:

Cartons, Bottles, Barrel, Stand-up Pouch, Bags, Foil, Belt

Packaging Material:

Plastic, Paper, Metal

Tangshan Rongcheng Science & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

XinGang

Delivery Detail:

Delivery time depends on order quantity.

Application Food, Commodity, Medical, Other, Apparel, Food, Commodity, Medical, Machinery & Hardware, Apparel

Packaging Type Cartons, Bottles, Barrel, Stand-up Pouch, Bags, Foil, Belt

Packaging Material Plastic, Paper, Metal

Automatic Grade Automatic

Driven Type Electric

Place of Origin China

Brand Name WanJie

Model Number WJ-TTR

Weight 465KG

Dimension(L*W*H) 1.1*0.95*1.3M

Certification CE and ISO9001

Specifications

1. Reverse direction for labels in lables out
2. Preset Batch and total count

Essential Functions:

1. Reverse direction for labels in lables out
2. Preset Batch and total count
3. Missing label detector. If a fault is detected, the machine will automatically stop immediately as the machine is equipped with a powder brake.
4. Banal inspection on splice sable.

Technical specification:

1. Frequency variation motor
2. Tension of the web controlled via powder brake
3. Digital counter with preselect
4. Fiber optic cells for counting (back and forward) and fault detection
5. Easily accessible control panel located on the front of the machine
6. Splicing table and inspection area
7. 2 rotary web plates of 400mm dia. (16”) equipped with interchangeable mechanical spindles (19mm, 25mm, 40mm, 76mm)
