Specifications
Double-station Label Die-cutting machine WJMQ-3501.Servo motor control
2.Electric eye tracer
3.Auto deviation
Double-station Label Die-cutting machine WJMQ-350
Characteristics:
- The machine adopts flat-bed mode and the material runs stably.
- Servo motor controls the driving to ensure precise material transportation.
- The machine has auto edge correction and mark tracking sensor which ensure high precise die-cutting.
- It can do die-cutting, waste-off, sheeting and rewinding in one process.
- It is optional for the machine to add separate unwinding unit, lamination, stamping and punching.
- Multi-function design makes the machine fit for adhesive, Nylon, laser anti-counterfeit and blank label die-cut. It is a complementary equipment for rotary label printing machine, flexo printer, screen printer etc.
Specification:
Items |
Specifications |
Unit |
Paper Width |
350 |
mm |
Max Die-cutting Size |
350*300 |
mm |
Max Die-cutting Speed |
210(Subject to the length and quality of the paper) |
times/min |
Main Power |
5.5 |
KW |
Overall Dimensions |
4425*1400*2050 (L*W*H) |
mm |
Machine Weight |
Appr.4000 |
kg |
