3 Horse Angle Load Float/ Trailer

3 Horse Angle Load Float/ Trailer thumbnail-1
3 Horse Angle Load Float/ Trailer photo-1
US$ 1 - 1 MOQ: 3 Sets
Key Specifications
Get Latest Price
Max Payload:
2600KG
Size:
6325*2280*2590mm
Place of Origin:
Hebei, China
Contact Supplier Request Quote Chat Now
Tangshan Rongcheng Science & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Max Payload 2600KG
Size 6325*2280*2590mm
Place of Origin Hebei, China
Brand Name RC
Model Number RC-HFT-02

Specifications

1. Max Payload: 2600KG
2. Size: 6325*2280*2590mm
3. With luxury human room
4. Extend 900mm
5. Double axles electronic brake

3 Horse Angle Load Float/ Trailer



Specifications



MODEL:RC-HFT-02



TRAILER MATERIALS

1.CHASSIS MATERIAL double hot dip galvanized RHS(3.5mm-4.0mm)

2. FRAME MATERIAL double hot dip galvanized RHS(2.5mm)

3 BODY PANEL galvanized (1.2mm)

4 ROOF special molded FRP 5475*1890*450mm

5 NUTS & BOLTS stainless steel



WHEELS & TYRES

1 WHEEL RIM 14' aluminium alloy rims

2 TYRES 185R14C

3 SPARE WHEEL one



AXLES & SUSPENSIONS

1 AXLES two special trailer axles

2 LEAF SPRINGS roll rocker tandem spring suspension 6 plates

3 BRAKE SYSTEM 4 wheel electric brakes



WINDOWS & DOORS

1 FRONT WINDOW 1220*610

2 SIDE WINDOWS 3 pop-up rectangle windows,2 sliding rectangular windows

3 VENTS three sash casement vent

4 SIZE OF SIDE DOOR 1755*615

5 REAR UPPER DOOR 2020*1065

6 RAMP DOOR 2020*1210

7 REAR UPPER & RAMP DOOR STRUT high-intensity anti-rust strut

8 HINGES FOR REAR UPPER DOOR special 6mm diameter copper hinges



DRAWBAR

1 DRAWBAR CHECKER PLATE 1.2mm aluminium

2 DRAWBAR SAFETY CHAIN two

3 BRACING WHEEL one



LIGHTS & RETRO REFLECTORS

1 TRAILER PLUGS square 7 wick plug

2 SIDE LAMPS 6

3 REAR LAMPS LED group

4 REAR LAMPS STAND aluminium

5 RETRO REFLECTORS 6



MUDGUARD

1 MUDGUARD TYPE compact mudguard

2 MUDGUARD CHECKER PLATE 1.2mm aluminium in the front of mudguard

3 PEDAL & ALUMINIUM STEP 1.2mm aluminium decoration board



INTERIOR & EXTERIOR

1 A KITCHEN with a cupboard and all appliance from yourself

2 HORSE PROTECTION FRAME full padded

3 HORSE RING six

4 RUBBER MATTING FOR RAMP DOOR 10mm rubber matting

5 RUBBER MATTING FOR FLOOR 10mm rubber matting

6 RUBBER MATTING FOR INNER SIDE PANEL 6mm rubber matting

7 WOOD BOARD FOR FLOOR & RAMP DOOR 18mm hardwood plywood

8 RUG RACK side

9 WATER TANK one set

10 SADDLE RACK in saddle box

11 SADDLE BOX 1500mm height for 3 saddles

12 PAINTING single or customized



DIMENSIONS

1 OVERALL DIMENSIONS ( L x W x H: mm ) 6325*2280*2590

2 BODY DIMENSIONS ( L x W x H: mm ) 5475*1980 *2230

3 MAXIMUM INTERNAL DEMENSION: 5450*1930*2155



OPTIONAL

Kitchen

Microwave

Sink

TV

Gas tank and gas oven

Fridge

Caravan door

Roof lining

Awning

Air-condition
