Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > CCTV Night Vision 1080P HD Zoom 30X Network Speed Dome 2MP PTZ Laser IP Camera
CCTV Night Vision 1080P HD Zoom 30X Network Speed Dome 2MP PTZ Laser IP Camera
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Coop
Model Number:
LC-36MSHD-IP 2MP PTZ Laser IP Camera
Payment & Shipping
Payment Methods:
Port of Shipment:
Quanzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Digital Camera Type and Dome Camera Style Full HD 20x/30x Network IR PTZ Dome CameraUS$ 600 - 700MOQ: 1 Piece -
Wholesale Camera IR 100M Outdoor 2MP FULL HD 20X Dome Network IR PTZ CameraUS$ 600 - 700MOQ: 1 Piece
-
2MP FULL HD 20X Network IR PTZ Dome WDR Camera WITH SAMSUNG SCM-6200NegotiableMOQ: 1 Piece
-
HD-SDI High Speed Dome With OSD PTZ CameraUS$ 38 - 70MOQ: 30 Pieces
-
High Speed Dome Wireless ip Camera PTZ IPUS$ 38 - 70MOQ: 30 Pieces
Place of Origin
Fujian, China
Brand Name
Coop
Model Number
LC-36MSHD-IP 2MP PTZ Laser IP Camera
Type
Analog Camera
Style
Dome Camera
Sensor
CMOS
Technology
NetWork
Special Features
Waterproof / Weatherproof
Specifications
2MP PTZ Laser IP Camera1.FCB-EH6500 Zoom
2.20X Optical Zoom
3.12X Digital Zoom
4.Image Stabilization
CCTV Night Vision 1080P HD Zoom 30X Network Speed Dome 2MP PTZ Laser IP Camera LC-36MSHD-IP
Product Description
2MP PTZ Laser IP Camera Features:
- Using aluminum alloy spherical shell design, part compact enclosures with high strength, good thermal property
- Using the primary system, cameras, infrared lamp module design of an isolation shell protection, waterproof performance, high reliability, camera positions internal nitrogen filled
- Using the latest third-generation infrared array (LED Array) light source. Infrared lamp high brightness, exposure, distance, light distribution, long service life .
- Infrared lamp brightness control function. Infra-red control lamp brightness control (indoor models), automation (outdoor models) and manually controlling the three modes, according to the monitoring target distances near and far, low, medium and high exposure to infrared lamp brightness to meet different range target infrared light irradiation when the monitor brightness requirements, most night vision distance up to 120 feet away, 6-array CPV LED
- Pan/Tilt with precision stepping motor driving, smooth, rapid and sensitive response, high positioning accuracy.
- Pan/Tilt speed is automatically adjusted: pan/tilt speed with zoom lens depth increases its speed gradually in proportion to lower.
- PTZ support multiple communication protocols and baud rate, high system compatibility.
- EEPROM data storage, user data is not lost when power.
- Pan360°continuously, Tilt 90°rotation, auto flip, humanize focus and speed proportion
- 128 presets(tiles can be set),1 tour;8 programmable zones(titles can be set); 4pattern, each record time is not less than 180s. Support 128 presets(extensible to 256), horizontal 360°, vertical 230°(up 15°). Support horizontal, vertical, pattern, with auto-flip function. Two random position storage/call, accurate positioning.
- 1scan, support scan repeatedly between right and left limit at an appointed speed.
- Support Scan, Tour, Pattern, Parking Time, Privacy Protection;
- IP 66 whole day defend cover.
- Support static IP(set the IP address, subnet mask, gateway and DNS);
- Support PPPOE, RTSP, VLC, NTP, UPNP; Support stream type switchable (composite or video stream); Support image parameters adjustable(brightness, contrast, hue, saturation); Support stream type switchable(CBR or VBR); Support 1ch probe detection, can set name of probe,open or closed mode,time of detection; Support multi area motion detection, can set motion area, sensitivity and time; Support privacy mask alarm, can set sensitivity and time
- Various modes for White Balance (Auto, ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp Fix/Auto, One-push, Manual)
- Picture effects (E-Flip, Nega Art, Black & White, Mirror Image, Colour Enhancement)
2MP PTZ Laser IP Camera Pictures:
2MP PTZ Laser IP Camera Specification:
| Model No. | LC-36MSHD-IP | |
| Camera | ||
| Zoom Type | FCB-EH6500 | |
| Image Sensor | 1/2.8-TYPE Exmor CMOS | |
| TVL | 1920*1080P | |
| Mini Workin Distance | 10mm(wide end ) to 1.200mm (tele end) (Default: 300mm) | |
| Mini Lux | High Sensitivty Mode | 0.5 Lux(F1.6 ICR OFF) 0.095Lux(F1.6 ICR ON) |
| Normal Mode | 1.7 Lux(F1.6 ICR OFF) 0.3Lux(F1.6 ICR ON) | |
| IR Light Angle | 6o—48° | |
| Video S/N Ratio | More than 50 dB (AGC: OFF) | |
| Auto Flip | Tilt down 90°, with auto-flip 180° | |
| Scan | 355° (Optional Setting ),4 Scans | |
| Decoder | Built-in | |
| Video Output Interface | Female BNC | |
| Remove Control | RS485/422 ,Manchester,BI-PHASE,Coaxial Video Control | |
| Baud Rate(RS485) | 2400/4800/9600/19200 bps | |
| ID Range | 1~254 | |
| Signal system | HD | 1080p/30,1080p/29.97, 1080p/25, 1080i/60(30PsF)/1080i/59.94 (29.97 PsF), 1080i/50 (25PsF), 720p/30, 720p/59.94, 720p/50,720p/30,720p/29.97, 720p/25 |
| SD | NTSC, PAL | |
| Video Output | HD | Analog: Component (Y/Pb/Pr) Digital: Y/Cb/Cr 4:2:2 via LVDS (Y: 8 bit, C: 8 bit) |
| SD | VBS: 1.0 Vp-p (sync negative) | |
| Camera control interface | VISCA (TTL signal level) Baud rate: 9.6 Kb/s, 19.2 Kb/s, 38.4 Kb/s | |
| Stop bit: 1/2 bit selectable | ||
| Electronic Shutter | 1/1 to 1/10,000 s, Total 22 steps | |
| White balance | Auto, ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp Fix/Auto, One-push, Manual | |
| Gain | Auto/Manual (-3 to +28 dB, +2 dB step/Total 16 steps) | |
| AE control | Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Slow AE | |
| Slow AE | Approx. 5 minutes | |
| Focusing system | Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity, Interval AF, Zoom Trigger AF | |
| Synchronization | Internal | |
| Lens | ||
| Lens | f=4.6~138.0mm | |
| f=4.6mm (wide) | ||
| 138.0mm(tele) F1.6 to F3.5 | ||
| Zoom Ratio | 30x Optical Zoom, 12x Ditgital Zoom | |
| View Angle | 1080p/30 mode: 59.5° (wide end) to 2.1° (tele end) 720p/60, 30 mode: 40.6° (wide end) to 1.4° (tele end) | |
| Pan and Tilt | ||
| Manual Speed | Pan (0.4°~180°/S) Tilt (0.4°~80°/S) | |
| Rotation | Pan 360°Continuously Tilt0-105° Auto Flip | |
| Focus Speed | Speed adjustable base on focus distane | |
| Preset | 128 | |
| Function | PRESET/TOUR/SCAN/PATTERN | |
| Display Zone | 8 editable title zone | |
| Alarm function | 7CH Alarm in, 2CH alarm out | |
| Video Out | 1.0Vp-p,75Ω,BNC Connector | |
| Communicate | RS485 Bus | |
| Protocol | PELCO-D,PELCO-P,KALATEL,VCL,MOLYNX,VICON etc | |
| Baud Rate | 2400/4800/9600/19200 bps | |
| Camera ID | 1~254 | |
| Infrared | ||
| IR Distance | 120M | |
| IR Instnsity | Automatically adjusted,depending on the zoom ratio | |
| Alarm | ||
| Alarm Input | 7 Alarm input | |
| Alarm Output | 2 Alarm Output | |
| Video | ||
| Compression | H.264 / MJPEG | |
| Resolution |
1080P(1920×1080)/ 720P(1280×720) / D1(704×576/ 704×480) /CIF (352×288/352×240) |
|
| Frame Rate | Main Stream | 1080P/ D1 (1 ~ 25/30fps), 720P(1~50/60fps) |
| Sub Stream | D1/CIF(1 ~ 25/30fps) | |
| Bit Rate | H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps | |
| Audio | ||
| compression | G.711a / G.711Mu(32kbps)/ PCM(128kbps) | |
| Interface | 1/1 channel In/Out | |
| Network | ||
| Thernet | RJ-45 (10/100Base-T) | |
| Protocol | PPPOE, RTSP, VLC, NTP, UPNP | |
| Compatibility | ONVIF | |
| Smart Phone | iPhone, iPad, Android, Windows Phone | |
| General | ||
| Menu Language | English,Chinese | |
| Environment Temperature | -40℃~+60℃ | |
| Environment Humidity | 0~95% (Non-Condensation) | |
| Protection Grade | IP66, TV4000V Light-proof, Surge-Proof, Wave-Proof | |
| Power | AC 24V±4V | |
| Comsuption | (PTZ+IR) 33W (PTZ+IR+Heating) 53W | |
| Dimension(HxD) | Φ200*353mm L520×W320×H300mm | |
| Weight | 9.68KG | |
2MP PTZ Laser IP Camera Auxiliary Bracket:
2MP PTZ Laser IP Camera Other Light Sources:
Laser PTZ Dome Camera White LED PTZ dome Camera
Night Vision:250M-300M Night Vision:100-120M
Company Information
COOP SECURITY(CHINA)LIMITED is one of the leading factories which develop and produce CCTV products in China, supported by the Chinese government as the most importantly developed company. All the models are produced by machine automatically.It has a Research and Development Center in Taiwan, possessing the most advanced patent for electronic R&D technique, leading us to be among the best in China.
Taipei Int'l Electronics Show
Packaging & Shipping
1. Transportation: UPS, TNT, DHL, EMS or FEDEX.
2. Item will be shipped out within 7 working days upon receipt of the payment.
3. Shipment may arrive within 5 – 16 days. Actual delivery days would be different for varies countries.
Our Services
1. Pls report us if there are any problem, we will solve it ASAP.
2. This items comes with 2 YEARS
FAQ
Q: How long your delivery time?
A: In general, the time is about one week.
Q: What’s your payment?
A: We accept payment by TT Bank Transfer in this stage.
2MP PTZ Laser IP Camera Similar Products:
