Specifications
High Speed Dome camera1/4 type interline transfer CCD
NTSC: 976(H)x494(V)
PAL: 976(H)x582(V)
2:1 scanning interlace
24X Optical Zoom Outdoor IR High Speed Dome Camera
1/4 type interline transfer CCD with 976 (H) x 494 (V) pixels (NTSC),
976 (H) x 582 (V) pixels (PAL)
36x Optical Auto focus Zoom lens : f=3.3 mm to 119.0 mm.
20x Digital Zoom : Up to 720x with optical zoom (GP-MS436)
24x Optical Auto focus Zoom lens : f=3.3 mm to 79.2 mm.
20x Digital Zoom : Up to 480x with optical zoom (GP-MS424)
650 TV lines typical at color and B/W imaging horizontal resolution.
Super Dynamic technology delivers 160x wider dynamic range compared to conventional cameras.
High sensitivity with True Day/Night function:
0.5 lx at color mode at F1.4 (Sens Up: Off, AGC: High)/
0.04 lx at B/W mode at F1.4 (Sens Up: Off, AGC: High).
Day/Night operation can be selected to automatically or manually switch from color to B/W.
Privacy Mask : Up to 8 mask can be displayed within one view angle.
Mirror and Up-Side-Down functions
VMD (Video Motion Detection)
DNR (Digital Noise Reduction). Image Stabilizer
Model |
HP-36MSIR |
HP-24MSIR |
|
Camera | |||
Image Sensor |
1/4 type interline transfer CCD |
||
Effective Pixels |
NTSC: 976(H)x494(V) PAL: 976(H)x582(V) |
||
Scanning Mode |
2:1 interlace |
||
Scanning Area |
3.6(H)x2.7(V) mm |
||
Horizontal Resolution |
650 TV line typical |
||
Minimum Illumination |
Color 0.5 lx (50 IRE, F1.4, Shutter: NTSC 1/60 sec, PAL 1/50 sec, Gain: High, Sense UP:OFF) B/W 0.04 lx (50 IRE, F1.4, Shutter: NTSC 1/60 sec, PAL 1/50 sec, Gain: High, Sense UP:OFF) |
||
Video S/N Ratio |
More than 50 dB (AGC: OFF) |
||
Backlight compensation |
Multi / Center / OFF (Mask settings possible) |
||
White Balance |
AWC / ATW / MWB (Adjustable R and B signals) / Outdoor / Indoor / Fluorescent |
||
Iris Conrtrol |
Auto / Manual |
||
AGC |
Low / Middle / High / OFF (Adjustable) |
||
Super Dynamic |
ON / OFF (ON: 54 dB typical) |
||
Electronic Shutter |
NTSC:1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10 000 sec. PAL :1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10 000 sec. Long shutter : x1, x2, x4, x6, x10, x16, x32, x64, x128, x256, x512 |
||
Electronic Sensitivity UP |
Auto / OFF, max 32x |
||
Electronic iris |
ON / OFF |
||
Day & Night (IR) |
Auto / Color / BW |
||
Digital Noise Reduction |
High / Low |
||
Gamma |
0.45 / 1 / SMART1 / SMART2 |
||
Video Motion Detection |
ON / OFF, adjustable sensitivities |
||
Privacy Mask |
ON / OFF, up to 8 zones |
||
Mirror Image Effect |
H/V / HV / OFF |
||
Image Stabilizer |
ON / OFF |
||
Camera Title (OSD) |
16 alphanumeric characters (cameraID:8 + Title:8) |
||
Auto Focus |
Auto / Manual / One-Push / Stop AF |
||
Aperture compensation |
ON / OFF (H/V settings possible) |
||
Synchronization |
Internal / External (V-sync.) |
||
LENS | |||
Focal Length |
3.3 mm ~119 mm / F1.4-4.2 |
3.3 mm ~ 79.2 mm / F1.4-2.8 |
|
Zoom Ratio |
36x Optical Zoom, 20x Ditgital Zoom |
24x Optical Zoom, 20x Ditgital Zoom |
|
View Angle |
Horizontal : 1.7°~ 60.2° Vertical : 1.3°~ 46.0° Diagonal : 2.2°~ 72.8° |
Horizontal : 2.7°~ 60.2° Vertical : 2.0°~ 46.0° Diagonal : 3.4°~ 72.8° |
|
Pan and Tilt | |||
Manual Speed |
Pan(0.4°~180°/S) Tilt(0.4°~80°/S) |
||
Rotation |
Pan 360°Continuously Tilt0-105° Auto Flip |
||
Focus Speed |
Speed adjustable base on focus distane |
||
Preset |
128 |
||
Function |
PRESET/TOUR/SCAN/PATTERN |
||
Display Zone |
8 editable title zone |
||
Alarm function |
7CH Alarm in, 2CH alarm out |
||
Video Out |
1.0Vp-p,75Ω,BNC Connector |
||
Communicate |
RS485 Bus |
||
Protocol |
PELCO-D,PELCO-P,KALATEL,VCL,MOLYNX,VICONEtc |
||
Baud Rate |
2400/4800/9600/19200 bps |
||
Camera ID |
1~254 |
||
Infrared | |||
IR Distance |
120M |
||
IR Instnsity |
Automatically adjusted,depending on the zoom ratio |
||
Alarm | |||
Alarm Input |
7 Alarm input |
||
Alarm Output |
2 Alarm Output |
||
Input/output | |||
Monitor Output |
NTSC: Composite, 1.0 Vp-p, 75 Ω PAL : Composite, 1.0 Vp-p, 75 Ω |
||
General | |||
Menu Language |
English,Chinese |
||
Working Temperature |
-40°C~+60°C |
||
Working Humidity |
0~95%(None condensation) |
||
Protection |
IP66,4000W lighting proof, wave proof, surge-proof |
||
Power |
AC 24V±4V |
||
Consumption |
(PTZ+IR)33W (PTZ+IR+Heating)53W |
||
Measure |
L520×W320×H300mm |
||
Weight |
9.68KG |
||
24X Optical Zoom Outdoor IR High Speed Dome Camera
