H.264 High Definition 5.0MP 1920P Network Box Camera

H.264 High Definition 5.0MP 1920P Network Box Camera thumbnail-1
H.264 High Definition 5.0MP 1920P Network Box Camera thumbnail-2
H.264 High Definition 5.0MP 1920P Network Box Camera thumbnail-3
H.264 High Definition 5.0MP 1920P Network Box Camera thumbnail-4
H.264 High Definition 5.0MP 1920P Network Box Camera photo-1
H.264 High Definition 5.0MP 1920P Network Box Camera photo-2
H.264 High Definition 5.0MP 1920P Network Box Camera photo-3
H.264 High Definition 5.0MP 1920P Network Box Camera photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
COOP
Model Number:
HD50BIPS
Contact Supplier Request Quote Chat Now
Coop Security Technology(Quanzhou)Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shipping from Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name COOP
Model Number HD50BIPS
Type Digital Camera
Style Box Camera
Sensor CMOS
Technology NetWork

Specifications

Super Low latency of 120ms,IR-Cut
audio broadcasting talk back
1ch alarm in/out
support ONVIF 2.0Version compatible

Onvif 5.0MP 1920P High Definition IP Box camera



Model NO.:HD50BIPS



H.264 High Definition 5.0MP 1920P Network Box Camera



.Elegant and fashionable design, Sophisticated ventilation cooling system, Easy to keep the machine working stability.

.5 MP 1920P HD real-time image output, Clear and realistic, Transmission fluently.

.Best Low-illuminance effect,Colour:0.1 lux(F1.7),B&W:0.01 lux (F1.7).

.IR-CUT Filter, Day /Night ,the day vision is color, night vision is B/W.

.H.264 video compression technologies, super Low stream can reproduce high definition picture quality, record the condition clearly.

.support Onvif2.0 standard version,support more open protocols: RTSP and VLC,Support video upload FTP.

.Dual stream transmission- Local High stream transmission and TF card record, WIFI network low stream to access, Noninterference, clearly image.

.Easily Communication;support alarm 1 in / 1out.

.Multifunctional tail interface support local output, TF card record, network access control, alarm linkage and function led so and on.

.Support Smartphone to remote access, icloud services, Remote browse the network, WIFI quick control, Can be equipped with the platform management, Access easy and convenient, accurate information security.

.Built-in 6KV Lightening-protection, Transient overvoltage protection to ensure safety.

.DC12V 3A low voltage. Support POE.



Parameters





F

Model No.

HD50BIPS

             General Function

Feature

High Resolution Ratio

CMOS Type

Aptina Imaging CMOS

CMOS Model

1/2.5″500MP

HD Output

Image Adjustable

1080P:2560×1920P

720P:1280×720P

D1:640×480

Illumination

Color:0.1Lux/B/W0.01Lux(F1.2,AGC ON)

IR Distance

Infrared

Shutter Speed

1/60Sec~ 1/100,000Sec,Shutter Speed Adjustable

Exposure Control

DSP Auto Adjust

AGC & WB

AGC:Auto(high, media, low )    White Balance:Auto,Close

S/N Ratio

≥50dB

Network Function

Network Steadiness

Auto Reconnect, Register, UPNP, HB Display, Synchronization

Support Agreement

Support Onvif2.0,PPPOE,DHCP,TCP/IP,HTTP,UDP,RTP/RTCP, RTSP,UPNP,SMTP,FTP,NTP,DDNS,DNS etc.

Dual Stream

Dual Stream Transfer(H.264,CBR/VBR Adjustable

Main Stream(1M~8Mbps)With Local Skim, SD Card etc.

Sub-Stream(0.5MK~2Mbps)With Network Transfer, 3G Visit.

upgrade,maintenance

Support Remote Upgrade, With Password Protect.

Wireless

Charge For Optional, WIFI

Special Function

Optional features

Charge For Optional, POE and TF Card Storage

Zoom function

Image Frame Selection Amplification Function, Convenient to Capture The Enlarged Picture Details

Smart alarm

Motion detect,Video Shelter,I/O Alarm for Video Lost, IP Address Conflict, Store Abnormal.

Video Efficiency

Effective Pixel

1280*1080

Video Frame Rate

50Hz/60Hz: 25fps,30fps,50fps,60fps are optioanal

Image Capture

JPEG for Local Storage

Image Setting

Saturation, Luminance, Contrast Ratio Adjustable Through Client or IE.

Image rolling-over

Level Transposition, Turn Up-Side Down, Easy for Install & Adjust.

Audio

Audio Encoding

With G.726/G.722/G.711 Standard Code,64Kbps Transfer Speed

Audio Function

Audio broadcast Audi playback

interface standard

Power Mount

DC Female Connector,5.5×2.1mm

Network Mount

1c h 10M/100M Ethernet mouth, RJ45 Mount

Video Output

1ch local Analog Output, BNC Interface.

Alarm Mount

1ch Alarm Input 1ch Alarm Output

Audio Mount

1ch Audio Input 1ch Audio Output

RS485 Mount

1ch RS485 Mount

Other standard

Working Enviroment

Enviroment Temperature-10°C~+60°C Camera Temperature: 25°C~35°C Humidity:<90%

Power Consumption

DC 12V±5% , IR LED ON(max): 6W

Product Size

Camera package:105 × 90 × 85 mm

Pack size

Camera weight:1.15 Kg~1.25 Kg



  Machine Size

H.264 High Definition 5.0MP 1920P Network Box Camera
