1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera

1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera thumbnail-1
1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera photo-1
US$ 51 - 66 MOQ: 1 set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Coopsecurity
Model Number:
HP-PA720PD-SDI Camera
Contact Supplier Request Quote Chat Now
Coop Security Technology(Quanzhou)Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name Coopsecurity
Model Number HP-PA720PD-SDI Camera
Type Analog Camera
Style Dome Camera
Sensor CMOS
Technology NetWork
Special Features Vandal-proof



1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera





Product Description



Model No.

HP-PA720PD-SDI

Image Sensor

1/3 inch progressive scan 1 Mega Pixel Panasonic CMOS Sensor

Effective pixels

1920(H) x 1080(V)

Scanning system

Progressive Scan

Minimum illumination

0.001 Lux

Lens

3M Pixels 3.6mm korea lens

IR view distance

20M with  24pcs 5 LEDs

WDR (Long and Short exposure)

OFF/ON(Level Adjustable)

O.S.D

Built-in

3D-DNR (3D Digital Noise Reduction)

OFF/ON(LOW/MIDDLE/HIGH)

Sens-Up

OFF/ON

Motion Detection

OFF/ON

Privacy Zone

OFF/ON

HLC

OFF/ON

B.L.C. control

OFF/ON

Defog

OFF/ON

White balance

AWB/ATW/PUSH/MANUAL

A.G.C

HIGH / LOW

Electronic shutter Speed

AUTO/MANUAL/FLK

Video output

HD-SDI(SMPTE 292M compatible) / CVBS:1.0 Vp-p Composite Signal (750hm)

Operation temperature

-10℃ - +50℃

Operation Humidity

Within 95% RH

Power supply

DC12V(+/-15%)

Power Consumption

100mA / IR LED ON:400mA Max

Dimensions (mm)

94*70(H)mm

Weight-Net (g)

480g



 1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera





HD-SDI CCTV DVR KIT

HD 1080P Security CCTV System HD-SDI DVR Kit 4/8 CH

Pls click the picture into the related web page.

1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera





Company Information

COOPSECURITY is professional security equipment supplier committe to provide secuiry surveillance goods.

There are wide range of security camera to cover everything. From home design camera with night vision and outdoor project bullet ip ptz and HD resolution camera. Also the related accessoires. All of product were technological updated contantly.

We are hoping to offer you the eco device that low power comsuption, good reliability long life and secure enviroment.

1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera

Fair

1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera

Certification if you need CE ROHS

1/3" Cmos 1 Mega Pixel Hot Top Metal Dome Housing IR Analog Camera HD-SDI Camera
