Specifications
4CH Real Time 1080P DVR2 Year Warranty
HD-SDI 1080P
Kindly operation
4CH RCA Real Time 1080P CCTV HD-SDI Camera Single channel playback DVD-RW Optional HD-SDI DVR 4CH
|
Model |
HP-1004H-SDI |
System |
Main processer
|
Industry level embedded microprocessor |
Operation system |
Embedded LINUX operation system |
|
System resource |
synchronous multi-channel recording, synchronous multi-channel sub-code stream, synchronous multi-channel playback, synchronous network operation |
|
Interface |
Operation interface |
16 bit true color graphical menu interface, mouse operation supportive |
display |
1/4 |
|
Video |
Video standard |
PAL;NTSC |
Image code |
H.264(High Profile) |
|
Surveillance image quality |
Monitor:1080p/D1;VGA: HDMI: |
|
Playback quality |
1080P,720P,D1/HD1/CIF/QCIF |
|
Coding capacity |
4CH 1080P Real time |
|
encoding capacity |
1CH 1080P Real time |
|
Multi mode input |
Support HD input,4ch 1080p |
|
Motion detection |
Area: 192(22 * 18) zone, Sensitivity optional |
|
Audio |
Audio compression |
G711A |
Talk-back |
Support |
|
|
Recording And Playback |
Recording mode |
manual >alarm>motion detect>timing |
Local playback |
Single channel playback, All channels playback |
|
Recording look-up mode |
Time searching, calendar searching, affair searching, channel searching, information searching |
|
|
Storage And Backup |
Hard disk capability for each channel |
Video:CIF 4~5G/day*ch,D1:16~20G/day*ch 960H:9~42G/day*ch 720P:10G~42G/day*ch;1080P:20G~80G/day*ch audio:691.2M/day*ch |
Recording storage |
Hard disk, network |
|
Backup mode |
Network, USB,SATA |
|
Video input |
4ch HD-SDI |
|
Video output |
2ch BNC(1.0Vp-p,75Ω)( 1ch Spot),1ch VGA,1ch HDMI |
|
Audio Input |
4CH RCA (200-2800mV,30KΩ) |
|
Audio output |
1ch RCA(200-3000mV,5KΩ) |
|
Alarm input |
16ch |
|
Alarm output |
4ch |
|
Network |
RJ45 10M/100M adoptive Ethernet network port |
|
PTZ control |
1 RS485,1 RS232; |
|
USB |
2pcs USB |
|
HDD |
2pcs SATA(each for Max.4TB) |
|
Wireless |
3G,WIFI |
|
Others |
Power |
ATX220V/100V |
Power consumption |
<15W(not including HDD) |
|
Work temperure |
0°C-+55°C |
|
Work humidity |
10%-90% |
|
Air pressure |
86kpa-106kpa |
|
Size |
260*230*60mm |
|
Weight |
9KG |
