Home > Products > HD-CVI DVR > 8CH DVR 800TVL home mobile security camera CCTV Camera system
8CH DVR 800TVL home mobile security camera CCTV Camera system
- 20000 Piece / Pieces per Month
- xiamen
- T/T L/C D/P D/A Credit Card
- Supply of Sodimax financial escort vehicle in-vehicle wireless 4G monitoring solution
- Supply school student delivery vehicle 4G wireless video real-time surveillance video recorder
- 4-channel 1080P single SD truck-mounted video recorder supports 4G network GPS full real-time monitoring
- SD Card 1080P HD Car Video Recorder H.264 Car Video Surveillance Solution
- 1080P HD MDVR Wifi GPS 3G Digital Video Recorder for School Bus CCTV System
- SD Card 720P HD Vehicle DVR H.264 Car Alarm Monitoring Solution
Product Details
Place of Origin: | Fujian, China | Brand Name: | COOP Standalone NVR | Model Number: | POE NVR |
Product Description
9 8CH DVR 800TVL home mobile security camera CCTV Camera system
Model | HP-8704P-AHD-MF | HP-8708P-AHD-MF | HP-8708P-AHD-MF | |
System | Main processer | Hisilicon 3521 | Hisilicon3531 | Hisilicon 3531 |
Video | Encode | H.264(High Profile); | H.264(High Profile); | H.264(High Profile); |
| Coding capacity | 4*720P@25fps | 8*720P@25fps | 16*720P@20fps |
| Decoding capacity | 4*720P@25fps | 8*720P@25fps | 16*720P@25fps |
| Multi-mode input | Analog: 4*720P (analog); 4*AHD-L(analog); Hybrid:4*720P@12fps(analog)+2*720P (network). Network: 2*1080P (network) + 2*720P(network); 8*720P(network);20*960H(network) | Analog : 8*720P ( analog) ; 8*AHD-L( analog) ; Hybrid : 4*720P ( analog) +4*720P (network) ; Network: 1*1080P ( network)+8*720P ( network) ; 4*1080P (network) ; 20*960H ( network) ; | Analog : 16*720P; 8*720P; 16*AHD-L; Hybrid : 4*720P ( analog) +4*720P(network) ; Network : 1*1080P+8*720P;4*1080P; 20*960H; |
Audio | Audio compression | G.711A | G.711A | G.711A |
| Talk-back | Support | Support | Support |
Recording & playback | Recording mode | Manual> Alarm> Motion Detection>Timing | Manual> Alarm> Motion Detection>Timing | Manual> Alarm> Motion Detection>Timing |
| Local playback | 4*720P@25fps | 8*720P@25fps | 1*720P@25fps |
Storage & Backup | Hard disk capability for each channel | 720P 20G/day; 960H 12~20G/day*channel; Audio: 691.2M/day*channel | 720P 20G/day; AHD-L 12~20G/day*channel; Audio: 691.2M/day*channel | 720P 20G/day; AHD-L 12~20G/day*channel; Audio: 691.2M/day*channel |
| Backup mode | Network backup, USB Hard Disk, USBrecording, SATArecording. | Network backup, USB Hard Disk, USB recording, SATArecording. | Network backup, USB Hard Disk, USB recording, SATArecording. |
Port | Video input | 4ch BNC | 8ch BNC | 16ch BNC |
| Video output | 1CH VGA, 1CH HDMI | 1CH VGA, 1CH HDMI | 1ch VGA, 1ch HDMI |
| Audio input | 4CH RCA | 2CH RCA | 2CH RCA |
| Audio output | 1CH RCA | 1CH RCA | 1CH RCA |
| Alarm input | N/A | N/A | N/A |
| Alarm output | N/A | N/A | N/A |
| Network | RJ45 10M/100M adaptive Ethernet network port | RJ45 10M/100M adaptive Ethernet network port | RJ45 10M/100M adaptive Ethernet network port |
| PTZ control | 1RS485; Support PTZ Controls | 1RS485; Support PTZ Controls | 1RS485; Support PTZ Controls |
| USB | 2x USB ports | 2x USB ports | 2x USB ports |
| HDD | 1 SATA ports (each max supports 4T) | 1 SATA ports (each max supports4T) | 1 SATA ports (each max supports4T) |
| Wireless port | 3G, WIFI (USB extension) | 3G, WIFI (USB extension) | 3G, WIFI (USB extension) |
Others | Power | 12V/3A | 12V/3A | 12V/3A |
| Size | 310mm(L)*245mm(W)*48mm(H) |
