Product Details
Place of Origin: | China | Brand Name: | Coop security | Model Number: | AHD Camera |
Type: | IP Camera | Style: | Dome Camera | Sensor: | CMOS |
Technology: | NetWork | Special Features: | Other, Vandal-proof, Vandal-proof |
Product Description
High quality OSD Menu 1.3Mega HDIS 960P Indoor AHD Camera
High quality OSD Menu 1.3Mega HDIS 960P Indoor AHD Camera CCTV Dome Camera Features:
1/3" HDIS 960P with IR CUT AHD Camera
CVBS output 16:9 image
The latest AHD high speed processor
Hidden cable bracket
Multi protection design: over-voltage protection/ static protection/lightning proof protection
Smart LED Infrared avoid over-exposure
bracket
Adopt Japan power IC Design, wide voltage, working voltage min. +5V, max.24V.
OSD Menu.
5-second-Press Menu left button and right button to switch CVBS and AHD output signal.
2.8-12mm VF Lens
1.3M 960P AHD output
CVBS output 16:9 image, 800TVL.
SONY 1.3Mega Exmor IMX238LQJ sensor
The latest AHD high speed processor
Super low illumination 0.0008LUX
OSD Menu.
5-second-Press Menu left button and right button to switch CVBS and AHD output signal.
2.8-12mm VF Lens
CCTV Dome Camera Technical sepc.:
Model Number | AHD-960P-YXND |
SENSOR | SONY 1/3” Exmor CMOS IMX238 |
Size | 32mm*32mm/38mm*38mm |
Chipset | NVP2430H+Sony238 |
Output Resolution | AHD 960P /CVBS 1300 TVL |
Signal Sys | PAL/NTSC |
Total Pixel | 1312(H)×1069(V) 1.4M Pixels |
Valid Pixel | 1280(H)×1024(V) 1.31M Pixels |
Min Illumination | Color 0.02Lux(F1.2,50IRE,AGC ON); B/W: 0.0008Lux(F1.2,50IRE,AGC ON) |
Electric Shutter | PAL :1/50 ~ 1/100,000s NTSC:1/60 ~ 1/100,000s |
WDR | D-WDR |
Sens-up | 0-30X |
2D-DNR | off/ low/ medium/ high |
3D-DNR | off/ low/ medium/ high |
Image-frozen | Support |
BLC/HLC | Support |
Defogger | 0-2 Level |
S/N | > 60dB |
White Balance | Auto White balance |
Day/Night | Auto/ manual / Color/ B/W |
Mirror | Horizontal/ Vertical |
Privacy Mask | Support |
OSD Language | Chinese/ English/ German/ French/ Italian/ Spanish/ Portuguese/ Russian/ Dutch/ Turkish/ Polish |
Video Output | 1.0Vp-p compound output, 75Ω |
Power | DC 12V±50% |
Working Temperature | -20℃~60℃ |
Working Humidity | Relative humidity less than 90% |
