ballscrew auto tool changer carousel panel furniture cnc router
Product description:
Our MISSILE-1325HP02 cnc router is designed for kinds of wooden working. Our panel furniture cnc router comes with 3 axis full ball screw transmission, Y axis twin square rail, auto tools changer carousel, servo driving system and syntec control system.
Parameters
| Index | Index | Parameter | Optional |
| Travel | X Travel | 1300mm(51") | <2000mm |
| Y Travel | 2500mm(98") | <5000mm | |
| Z Travel | 200mm | <700mm | |
| Precision | working precision | 0.02mm | |
| Repostion | 0.05mm | ||
| Structure | Table structure | vacuum adsorption | |
| X.Y.Z structure | X.Y Z axis ball screw | ||
| speed | Max air line speed | 50000mm/min | |
| Max working speed | 25000mm/min | ||
| spindle | spindle power | 9.0kw | |
| running speed | 0-18000r/min | ||
| Mede of Operation | YASKAWA servo | ||
| Working vottage | AC 380V/50HZ | AC 380V/60HZ | |
| Dictate of operation | G code | ||
| Opera .ting system | Syntec | ||
| Net weight | 2000kg | ||
| Gross weight | 2300kg |
Features
Our MISSILE-1325HP02 tool changer carousel panel furniture cnc router is extremely heavy duty work center with 3 axis ball screw that features high speed precision positioning.
1. An entry-level all-rounder, tool changer carousel, extraordinary solution with competitive price.
2. Using world-class components, e.g. HSD 9kw ATC spindle, Japan Yaskawa servo motor driving system, France gear reducer, Delta inverter—guaranteeing optimum performance and minimum failure.
3. Versatile functions: routing, drilling, cutting, side-milling, edge chamfering, etc.
4. T-slot vacuum table with great absorption strength—absorb on multi-zone or clamp with pop-up positioning pin, it is your call.
5. Boring aggregate optional.
Thanks to its special safety design without safety guards the operator can access the machine from all four sides.
The accessory
The panel furniture cnc router is designed to provide a solid foundation for high quality machining, but keep the cost affordable for smaller budgets.
YASKAWA Servo System Syntec control cabinet Vacuum pump
HSD 9KW tool changer spindle Carousel tool magazine Vacuum table
Our MISSILE serial is customize high level model, there are wood cnc router, advertising cnc router, ballscrew panel furniture cnc router and high precise cnc router for cutting aluminum. We can product machine meeting your requirement.
The samples & application
Auto tool changer carousel cnc router with 3 controlled axis equipped with matrix table for nesting operations on wood or its derivatives, plastic or composite materials.
- Furniture indystry, solid wood furniture, solid wood doors, decorative materials, computer tables, panel furniture, office furniture, wooden speaker amd kitchenware, etc. It also can process automobile mould and non-metalic mould
Our Company:
1.We can guarantee the machine made in our factory, all have our brand: If you need to check, welcome to our company and visit our factory.
2.We have specialists on the CNC Router Machine researched, including all kinds of machines: like woodworking CNC Router, Stone CNC Router, CNC Router with Pneumatic Tool Changer and Automatic Tool Changing CNC Router, Advertising CNC Router etc.
3. based on the strong sales network and stable quality, for the best selling products we all have wide stock to make satisfied with your needs, then save your time and money on the shipment.
4.we have the technical sales managers who can speak fluent English,answer you questions in 24 hours.
Workshop
FAQ
1.Question: what is this machine used for? Do i need a cnc router?
This machine can be used for furnitures engraving, room decorations, industrial equipment parts, music instrument, mold, art&craft, building models and advertisment industry.
2.Question: How can i find a machine which can satify my requirement within my budget? Which one is the right one for me?
1)What is the most complex design?
Do you plan to use the machine for cutting, carving, drilling, or all of the above?
2)X axis ( ____ )mm------W
Y axis ( ____ )mm ------L
Z axis ( ____ )mm ------H
3. Question: What is the machine warranty?
Our machine are with one year qualtiy warranty.
