drywall angle beads /corner bead/metal corner bead

Specifications

Angle Bead
Material:aluminium, pvc, Carbon steel or stainless steel.
Thickness:0.25-0.50mm
Wing Width:20mm, 23mm, 25mm, 30mm

Angle Bead ( Corner Bead )have a smooth round nose bead with diamond mesh wings for the keying of plaster right up to the nose of the bead.On the outside is the finished edge which is where one side of your drywall knife runs on when you are applying drywall mud. The two flanges sit flat on your raw drywall. The diamond decoration along the length of the flange act as a keyway for holding the drywall mud to the drywall and the corner. This mesh insures a perfect bond and provides effective reinforcement where most needed. Straight edge nose is easy to install and permits plumb straight outside corners. Excellent protection for corridor corners exposed to traffic.



Angle Beads are designed for internal use and outer plaster uses, manufactured from quality galvanized steel sheet, expanded or perforated mesh. Can be reinforced with flange wings or standard beads.



Angle Bead (corner beads) may form straight side on the edge line of plaster project to fight break or chap and strengthen the most fragile part of the plaster. Its wing may enter the plaster in any edge line strongly.
Angle Beads can be supplied in expanded metal or perforated metal, mainly used for plastering of walls. Finishes can be hot dipped zinc coating or electro galvanizing.
1)Angle Bead is used in plasterwork for outside (external)corners of concrete columns of wall. 2)it protects corner plastering against cracks and chipping at the same time provide a straight arris for better finishing.

We can offer the following corner bead:
Expanded Angle Bead;
Perforated Angle Bead;
Angle Bead with Reinforce Flange;
Angle Bead with creased Reinforce Flange;



Angle Bead Material: aluminium, pvc, Carbon steel or stainless steel.
Thickness: 0.25-0.50mm

Edge:40,50mm

Wing Width: 20mm, 23mm, 25mm, 30mm, 35mm and so on.
Length: No limited



Angle Bead Specifications:



Expanded Angle Bead

Material	Edge	Length	Weight (Kg/m)	Pes/ box	Boxes/ pallet
Galv.steel	45mm	2.7m	0.123	40	25



Perforated Angle Bead

Material	Edge	Length	Weight (Kg/m)	Pes/ box	Boxes/ pallet
Galv.steel	45mm	2.7m	0.128	40	25



Angle Bead with Reinforce Flange

Material	Edge	Length	Weight (Kg/m)	Pes/ box	Boxes/ pallet
Galv.steel	30.5mm	2.7m	0.143	40	25



Angle Bead with Creased Reinforce Flange

Material	Edge	Length	Weight (Kg/m)	Pes/ box	Boxes/ pallet
Galv.steel	56mm	2.7m	0.24	40	25
